Waveguide Junction Circulators

Theory and Practice

Inbunden, Engelska, 1998

4 676 kr

Beställningsvara. Skickas inom 7-10 vardagar. Fri frakt över 249 kr.

Beskrivning

Waveguide Junction Circulators brings together for the first time all the design aspects of this class of device. In a typical application the circulator allows a single antenna to be used for both transmission and reception. Together with semiconductor, passive and electronic devices, the circulator constitutes an essential building block in modern radar, satellite and telecommunication equipment. Features include:* Examination of the properties and adjustments of the 3-port junction circulator and focus on the gyromagnetic resonator* Description of the design of practical classic circulator arrangements* Discussion of aspects of filter theory in the design of the classic 3-port junction circulator* Consideration of practical concerns such as insertion loss and commercial specificationsWritten by a leading academic authority and experienced industrial consultant, Waveguide Junction Circulators is a vital information source for designers working in microwave engineering. This valuable guide provides the academic researcher with a firm foundation in the theoretical aspects of this class of device whilst offering the industrial engineer an experimental platform for commercial design.

Produktinformation

Utgivningsdatum:1998-09-24
Mått:172 x 247 x 36 mm
Vikt:1 077 g
Format:Inbunden
Språk:Engelska
Antal sidor:560
Förlag:John Wiley & Sons Inc
ISBN:9780471982524

Utforska kategorier

Elektronik och kommunikationer inom Naturvetenskap och teknik

Mer om författaren

Joseph Helszajn,, PhD, is an international authority on non-reciprocal microwave circuits and devices. He has made a significant contribution to the characterization of the complex gyrator circuits and gain-bandwidth products of planar gyromagnetic resonators and other gyromagnetic devices. Professor Helszajn is a Fellow of the Institute of Electrical and Electronic Engineers, the City and Guilds Institute, the Royal Society of Edinburgh and the Royal Academy of Engineering. He previously authored thirteen books, nine of which were published by Wiley.

Innehållsförteckning

Preface ix1 Architecture of Symmetrical Waveguide Junction Circulators 12 Scattering Matrix of m-Port Circulator 233 Eigenvalue Adjustment pf 3-Port Circulator 394 Impedance Matrix of Junction Circulator 575 The Post Gyromagnetic Resonator 776 Okada Resonator 897 Isotropic, Anisotropic and Gyromagnetic Circular Waveguides 1098 Isotropic, Anisotropic Open Circular Wavelengths 1399 The Dialectric Cavity Resonator 15510 The Gyromagnetic Cavity Resonator 17911 Impedance in Rectangular, Ridge and Radial Waveguides 19912 Junction Circular Using Post Resonators 22913 Complex Gyrator Circuit of a Waveguide Junction Circulator using an Okada Resonator 25514 Degree-1 and 2 Okada Circulators 27915 An Evanescent Mode Okada Junction Circulator 29716 Complex Gyrator Circuit of an H-Plane Junction Circulator using an Okada Resonator 31117 Complex Gyrator Circuit of an Evanescent-Mode E-Plane Junction Circulator using H-Plane Turnstile Resonators 33918 Waveguide Circulators using Triangular and Prism Resonators 35919 Synthesis of Quarter-Wave Coupled Junction Circulators with Degrees 1 and 2 Complex Gyrator Circuits 37920 The 4-Port Single Junction Waveguide Circulator 39921 Microwave Switching using Junction Circulators 43122 Insertion Loss of Waveguide Circulators 43123 Synthesis of Stepped Impedance Transducers 44524 Experimental Evaluation of Junction Circulators 47125 Circulator Specifications 48926 Gyromagnetic Effect in Magnetic Insulator 511Index 537
