Beginner's Guide to Reading Schematics, Fourth Edition

Stan Gibilisco is a professional technical writer who specializes in books on electronics and science topics. He is the author of The Encyclopedia of Electronics, The McGraw-Hill Encyclopedia of Personal Computing, and The Illustrated Dictionary of Electronics, as well as over 20 other technical books. His published works have won numerous awards. The Encyclopedia of Electronics was chosen a "Best Reference Book of the 1980s" by the American Library Association, which also named his McGraw-Hill Encyclopedia of Personal Computing a "Best Reference of 1996."

• Introduction1 The Master PlanBlock DiagramsSchematic DiagramsSchematic SymbologyComponent InterconnectionsA Visual Language2 Block DiagramsA Simple ExampleFunctional DrawingsCurrent and Signal PathsFlowchartsProcess PathsSummary3 Components and DevicesResistorsCapacitorsInductors and TransformersSwitches and RelaysConductors and CablesDiodes and TransistorsOperational AmplifiersElectron TubesElectrochemical Cells and BatteriesLogic GatesSummary4 Simple CircuitsGetting StartedComponent LabelingTroubleshooting with SchematicsA More Sophisticated DiagramSchematic/Block HybridsA Vacuum-Tube RF AmplifierThree Basic Logic CircuitsSummary5 Complex CircuitsIdentifying the Building BlocksPage BreaksSome More CircuitsGetting Comfortable with Large SchematicsOp Amp CircuitsSummary6 Diagrams for Building And TestingYour BreadboardWire WrappingKirchhoff’s Current LawKirchhoff’s Voltage LawA Resistive Voltage DividerA Diode-Based Voltage ReducerMismatched Lamps in SeriesA Compass-Based GalvanometerSummary and ConclusionA Schematic SymbolsB Resistor Color CodesC Parts SuppliersSuggested Additional ReadingIndex
