Kaixue Ma – författare

Substrate Integrated Suspended Line Circuits and Systems provides a systematic overview of the new transmission line - the substrate-integrated suspension line (SISL). It details the fundamentals and classical application examples of the SISL. The basic SISL concept and structure, various passive circuits and active circuits, and front-end sub-systems are systematically introduced. Featuring research on topics such as high-performance RF/microwave/mm-wave circuits and system, this book is ideal for researchers, engineers, scientists, scholars, educators, and students. Since transmission line is a fundamental component of microwave and mm-wave circuits, the properties of a transmission line, such as losses, size, and dispersion, are vital to the performance of the whole system. Suspended line has been proved to be an excellent transmission line, as it has attractive features such as low loss, weak dispersion, high power capacity, and low effective dielectric constant. However, Conventional waveguide suspended line circuits require metal housing to form air cavities which is Substrate Integrated Suspended Line Circuits and Systems essential to the operation of suspended lines circuits. Also, the metal shell should provide mechanical support and shielding, which contribute to large size and heavy weight. Meanwhile, precise mechanical fabrication and assembling are strongly required, which brings difficulties to the design and fabrication of conventional suspended line circuits, and the manufacturing cost of suspended line circuits increases correspondingly. In this book, we will introduce a new platform of high-performance transmission line, i.e. substrate integrated suspended line (SISL). SISL keeps all the merits of the suspended line while overcomes the drawbacks of conventional waveguide suspended line circuits. Moreover, it is self-packaged and highly integrated. The basic SISL concept and structure, various passive circuits and active circuits, and front-end sub-systems will be systematically introduced. Featuring research on topics such as high-performance RF/microwave/mm-wave circuits and system, this book is ideally designed for researchers, engineers, scientists, scholars, educators, and students.

The increasing demand for extremely high-data-rate communications has urged researchers to develop new communication systems. Currently, wireless transmission with more than one Giga-bits-per-second (Gbps) data rates is becoming essential due to increased connectivity between different portable and smart devices. To realize Gbps data rates, millimeter-wave (MMW) bands around 60 GHz is attractive due to the availability of large bandwidth of 9 GHz. Recent research work in the Gbps data rates around 60 GHz band has focused on short-range indoor applications, such as uncompressed video transfer, high-speed file transfer between electronic devices, and communication to and from kiosk. Many of these applications are limited to 10 m or less, because of the huge free space path loss and oxygen absorption for 60 GHz band MMW signal. This book introduces new knowledge and novel circuit techniques to design low-power MMW circuits and systems. It also focuses on unlocking the potential applications of the 60 GHz band for high-speed outdoor applications. The innovative design application significantly improves and enables high-data-rate low-cost communication links between two access points seamlessly. The 60 GHz transceiver system-on-chip provides an alternative solution to upgrade existing networks without introducing any building renovation or external network laying works.

Power consumption has become a critical concern in RF/mm-wave integrated circuit (IC) design thanks to new applications from 5G, mobile computing, artificial intelligence, and the Internet of Things. However, big challenges lie ahead for chip designers when they choose to develop ICs using silicon technology for low-power and high-data-rate applications. This is because silicon technology suffers from undesirable energy dissipation due to its lossy substrate and high resistive wiring loss at GHz frequencies. Nonetheless, silicon remains the most suitable material satisfying the demands of a rapidly growing semiconductor market through low fabrication cost and ease of achieving system-on-chip or system-in-package integration. While long being neglected, low-power RF/mm-wave design has vaulted to the forefront of attention in recent years due to the demand for ultra-low-power transceivers to achieve sustainability. Designing genuinely ubiquitous transceivers for these new applications requires innovations in both system architecture and circuit implementation.This book closes the gap between a typical textbook with theories that are difficult to understand and a design-oriented book that offers little insight into actual theories. It evaluates and discusses different circuit topologies, receiver and transmitter architectures, phase-locked loop performance metrics, phase noise analysis, and sub-system-level designs that have yet to be reported in other books.

This book delves deeply into the substrate integrated suspended line antenna technologies and evaluates its potential to replace conventional three-dimensional (3D) metal-based antennas.
