Muhammad H. Rashid – författare

The purpose of this book is to describe the theory of Digital Power Electronics and its applications. The authors apply digital control theory to power electronics in a manner thoroughly different from the traditional, analog control scheme. In order to apply digital control theory to power electronics, the authors define a number of new parameters, including the energy factor, pumping energy, stored energy, time constant, and damping time constant. These parameters differ from traditional parameters such as the power factor, power transfer efficiency, ripple factor, and total harmonic distortion. These new parameters result in the definition of new mathematical modeling:• A zero-order-hold (ZOH) is used to simulate all AC/DC rectifiers.• A first-order-hold (FOH) is used to simulate all DC/AC inverters.• A second-order-hold (SOH) is used to simulate all DC/DC converters.• A first-order-hold (FOH) is used to simulate all AC/AC (AC/DC/AC) converters.- Presents most up-to-date methods of analysis and control algorithms for developingpower electronic converters and power switching circuits- Provides an invaluable reference for engineers designing power converters, commercialpower supplies, control systems for motor drives, active filters, etc.- Presents methods of analysis not available in other books

Power electronics, which is a rapidly growing area in terms of research and applications, uses modern electronics technology to convert electric power from one form to another, such as ac-dc, dc-dc, dc-ac, and ac-ac with a variable output magnitude and frequency. It has many applications in our every day life such as air-conditioners, electric cars, sub-way trains, motor drives, renewable energy sources and power supplies for computers. This book covers all aspects of switching devices, converter circuit topologies, control techniques, analytical methods and some examples of their applications.Designed to appeal to a new generation of engineering professionals, Power Electronics Handbook, 3rd Edition features four new chapters covering renewable energy, energy transmission, energy storage, as well as an introduction to Distributed and Cogeneration (DCG) technology, including gas turbines, gensets, microturbines, wind turbines, variable speed generators, photovoltaics and fuel cells, has been gaining momentum for quite some time now.smart grid technology. With this book readers should be able to provide technical design leadership on assigned power electronics design projects and lead the design from the concept to production involving significant scope and complexity.- Contains 45 chapters covering all aspects of power electronics and its applications- Three new chapters now including coverage Energy Sources, Energy Storage and Electric Power Transmission- Contributions from more than fifty leading experts spanning twelve different countries

This new resource is a practical overview of designing, testing and troubleshooting power electronics in alternative energy systems, providing you with the most important information on how power electronics components such as inverters, controllers and batteries can play a pivotal role in the successful implementation of green energy solutions for both stand-alone and grid-connected applications. You will learn how to choose the right components for diverse systems, from utility-scale wind farms to photovoltaic panels on single residences, how to get the most out of existing systems, and how to solve the tough challenges particular to alternative energy applications. Whether you are a renewables professional who needs to understand more about how power electronics impact energy output, or a power engineer who is interested in learning what new avenues the alternative energy revolution is opening for your work, start here with advice and explanations from the experts, including equations, diagrams and tables designed to help you understand and succeed.- Provides a thorough overview of the key technologies, methods and challenges for implementing power electronics in alternative energy systems for optimal power generation- Includes hard-to-find information on how to apply converters, inverters, batteries, controllers and more for stand-alone and grid-connected systems- Covers wind and solar applications, as well as ocean and geothermal energy, hybrid systems and fuel cells

This new resource is a practical overview of designing, testing and troubleshooting power electronics in alternative energy systems, providing you with the most important information on how power electronics components such as inverters, controllers and batteries can play a pivotal role in the successful implementation of green energy solutions for both stand-alone and grid-connected applications. You will learn how to choose the right components for diverse systems, from utility-scale wind farms to photovoltaic panels on single residences, how to get the most out of existing systems, and how to solve the tough challenges particular to alternative energy applications. Whether you are a renewables professional who needs to understand more about how power electronics impact energy output, or a power engineer who is interested in learning what new avenues the alternative energy revolution is opening for your work, start here with advice and explanations from the experts, including equations, diagrams and tables designed to help you understand and succeed. Provides a thorough overview of the key technologies, methods and challenges for implementing power electronics in alternative energy systems for optimal power generation Includes hard-to-find information on how to apply converters, inverters, batteries, controllers and more for stand-alone and grid-connected systems Covers wind and solar applications, as well as ocean and geothermal energy, hybrid systems and fuel cells

- This derivative volume stemming from content included in our seminal Power Electronics Handbook takes its chapters related to renewables and establishes them at the core of a new volume dedicated to the increasingly pivotal and as yet under-published intersection of Power Electronics and Alternative Energy. While this re-versioning provides a corollary revenue stream to better leverage our core handbook asset, it does more than simply re-package existing content. Each chapter will be significantly updated and expanded by more than 50%, and all new introductory and summary chapters will be added to contextualize and tie the volume together. Therefore, unlike traditional derivative volumes, we will be able to offer new and updated material to the market and include this largely original content in our ScienceDirect Energy collection.- Due to the inherently multi-disciplinary nature of renewables, many engineers come from backgrounds in Physics, Materials, or Chemical Engineering, and therefore do not have experience working in-depth with electronics. As more and more alternative and distributed energy systems require grid hook-ups and on-site storage, a working knowledge of batteries, inverters and other power electronics components becomes requisite. Further, as renewables enjoy broadening commercial implementation, power electronics professionals are interested to learn of the challenges and strategies particular to applications in alternative energy. This book will bring each group up-to-speed with the primary issues of importance at this technological node.- This content clarifies the juncture of two key coverage areas for our Energy portfolio: alternative sources and power systems. It serves to bridge the information in our power engineering and renewable energy lists, supporting the growing grid cluster in the former and adding key information on practical implementation to the latter.- Provides a thorough overview of the key technologies, methods and challenges for implementing power electronics in alternative energy systems for optimal power generation- Includes hard-to-find information on how to apply converters, inverters, batteries, controllers and more for stand-alone and grid-connected systems- Covers wind and solar applications, as well as ocean and geothermal energy, hybrid systems and fuel cells

This derivative volume stemming from content included in our seminal Power Electronics Handbook takes its chapters related to renewables and establishes them at the core of a new volume dedicated to the increasingly pivotal and as yet under-published intersection of Power Electronics and Alternative Energy. While this re-versioning provides a corollary revenue stream to better leverage our core handbook asset, it does more than simply re-package existing content. Each chapter will be significantly updated and expanded by more than 50%, and all new introductory and summary chapters will be added to contextualize and tie the volume together. Therefore, unlike traditional derivative volumes, we will be able to offer new and updated material to the market and include this largely original content in our ScienceDirect Energy collection.

Due to the inherently multi-disciplinary nature of renewables, many engineers come from backgrounds in Physics, Materials, or Chemical Engineering, and therefore do not have experience working in-depth with electronics. As more and more alternative and distributed energy systems require grid hook-ups and on-site storage, a working knowledge of batteries, inverters and other power electronics components becomes requisite. Further, as renewables enjoy broadening commercial implementation, power electronics professionals are interested to learn of the challenges and strategies particular to applications in alternative energy. This book will bring each group up-to-speed with the primary issues of importance at this technological node.

This content clarifies the juncture of two key coverage areas for our Energy portfolio: alternative sources and power systems. It serves to bridge the information in our power engineering and renewable energy lists, supporting the growing grid cluster in the former and adding key information on practical implementation to the latter. Provides a thorough overview of the key technologies, methods and challenges for implementing power electronics in alternative energy systems for optimal power generation Includes hard-to-find information on how to apply converters, inverters, batteries, controllers and more for stand-alone and grid-connected systems Covers wind and solar applications, as well as ocean and geothermal energy, hybrid systems and fuel cells

Power Electronics Handbook, Fourth Edition, brings together over 100 years of combined experience in the specialist areas of power engineering to offer a fully revised and updated expert guide to total power solutions. Designed to provide the best technical and most commercially viable solutions available, this handbook undertakes any or all aspects of a project requiring specialist design, installation, commissioning and maintenance services.Comprising a complete revision throughout and enhanced chapters on semiconductor diodes and transistors and thyristors, this volume includes renewable resource content useful for the new generation of engineering professionals. This market leading reference has new chapters covering electric traction theory and motors and wide band gap (WBG) materials and devices. With this book in hand, engineers will be able to execute design, analysis and evaluation of assigned projects using sound engineering principles and adhering to the business policies and product/program requirements.- Includes a list of leading international academic and professional contributors- Offers practical concepts and developments for laboratory test plans- Includes new technical chapters on electric vehicle charging and traction theory and motors- Includes renewable resource content useful for the new generation of engineering professionals

Handbook of Power Electronics in Smart Grids and Intelligent Energy is an expert guide to smart grids, intelligent energy, artificial intelligence, and machine learning applications increasingly enabled by modern grid-aware power electronics converters. The work is designed to provide clear technical presentation with a focus on commercial viability, and it supports any or all aspects of a project requiring specialist design, analysis, installation, commissioning, and maintenance services. With this book in hand, engineers will be able to execute design, analysis, and evaluation of assigned projects using sound engineering principles and adhering to the business policies and product/program requirements.It supports power electronics engineers and researchers interested in new approaches to advance smart grid security, resiliency, energy management, energy efficiency, diagnostics and control systems and power electronics interfaces.

Includes technical coverage of attractive spaces such as power electronics applications in integrated renewable energy systems, smart storage, smart grids and cybersecurityOffers support and guidance, with detailed examples and applications for laboratory test plans and field experimentationProvides a fully comprehensive work that addresses each aspect in unusual depth and technical presentation with 27 chapters and over 500 pages

Handbook of Power Electronics in Smart Grids and Intelligent Energy is an expert guide to smart grids, intelligent energy, artificial intelligence, and machine learning applications increasingly enabled by modern grid-aware power electronics converters. The work is designed to provide clear technical presentation with a focus on commercial viability, and it supports any or all aspects of a project requiring specialist design, analysis, installation, commissioning, and maintenance services. With this book in hand, engineers will be able to execute design, analysis, and evaluation of assigned projects using sound engineering principles and adhering to the business policies and product/program requirements.It supports power electronics engineers and researchers interested in new approaches to advance smart grid security, resiliency, energy management, energy efficiency, diagnostics and control systems and power electronics interfaces. - Includes technical coverage of attractive spaces such as power electronics applications in integrated renewable energy systems, smart storage, smart grids and cybersecurity- Offers support and guidance, with detailed examples and applications for laboratory test plans and field experimentation- Provides a fully comprehensive work that addresses each aspect in unusual depth and technical presentation with 27 chapters and over 500 pages

Handbook of Power Electronics in Autonomous and Electric Vehicles provides advanced knowledge on autonomous systems, electric propulsion in electric vehicles, radars and sensors for autonomous systems, and relevant aspects of energy storage and battery charging. The work is designed to provide clear technical presentation with a focus on commercial viability. It supports any and all aspects of a project requiring specialist design, analysis, installation, commissioning and maintenance services. With this book in hand, engineers will be able to execute design, analysis and evaluation of assigned projects using sound engineering principles and commercial requirements, policies, and product and program requirements.- Presents core power systems and engineering applications relevant to autonomous and electric vehicles in characteristic depth and technical presentation- Offers practical support and guidance with detailed examples and applications for laboratory vehicular test plans and automotive field experimentation- Includes modern technical coverage of emergent fields, including sensors and radars, battery charging and monitoring, and vehicle cybersecurity

Power Electronics Handbook, Fifth Edition delivers an expert guide to power electronics and their applications. The book examines the foundations of power electronics, power semiconductor devices, and power converters, before reviewing a constellation of modern applications. Comprehensively updated throughout, this new edition features new sections addressing current practices for renewable energy storage, transmission, integration, and operation, as well as smart-grid security, intelligent energy, artificial intelligence, and machine learning applications applied to power electronics, and autonomous and electric vehicles. This handbook is aimed at practitioners and researchers undertaking projects requiring specialist design, analysis, installation, commissioning, and maintenance services. Provides a fully comprehensive work addressing each aspect of power electronics in painstaking depth Delivers a methodical technical presentation in over 1500 pages Includes 50+ contributions prepared by leading experts Offers practical support and guidance with detailed examples and applications for lab and field experimentation Includes new technical sections on smart-grid security and intelligent energy, artificial intelligence, and machine learning applications applied to power electronics and autonomous and electric vehicles Features new chapter level templates and a narrative progression to facilitate understanding

Power Electronics Handbook, Fifth Edition delivers an expert guide to power electronics and their applications. The book examines the foundations of power electronics, power semiconductor devices, and power converters, before reviewing a constellation of modern applications. Comprehensively updated throughout, this new edition features new sections addressing current practices for renewable energy storage, transmission, integration, and operation, as well as smart-grid security, intelligent energy, artificial intelligence, and machine learning applications applied to power electronics, and autonomous and electric vehicles. This handbook is aimed at practitioners and researchers undertaking projects requiring specialist design, analysis, installation, commissioning, and maintenance services.- Provides a fully comprehensive work addressing each aspect of power electronics in painstaking depth- Delivers a methodical technical presentation in over 1500 pages- Includes 50+ contributions prepared by leading experts- Offers practical support and guidance with detailed examples and applications for lab and field experimentation- Includes new technical sections on smart-grid security and intelligent energy, artificial intelligence, and machine learning applications applied to power electronics and autonomous and electric vehicles- Features new chapter level templates and a narrative progression to facilitate understanding

Handbook of Power Electronics in Autonomous and Electric Vehicles provides advanced knowledge on autonomous systems, electric propulsion in electric vehicles, radars and sensors for autonomous systems, and relevant aspects of energy storage and battery charging. The work is designed to provide clear technical presentation with a focus on commercial viability. It supports any and all aspects of a project requiring specialist design, analysis, installation, commissioning and maintenance services. With this book in hand, engineers will be able to execute design, analysis and evaluation of assigned projects using sound engineering principles and commercial requirements, policies, and product and program requirements.Presents core power systems and engineering applications relevant to autonomous and electric vehicles in characteristic depth and technical presentationOffers practical support and guidance with detailed examples and applications for laboratory vehicular test plans and automotive field experimentationIncludes modern technical coverage of emergent fields, including sensors and radars, battery charging and monitoring, and vehicle cybersecurity

Power electronics can be a difficult course for students to understand and for professional professors to teach, simplifying the process for both. LTspice for power electronics and electrical power edition illustrates methods of integrating industry-standard LTspice software for design verification and as a theoretical laboratory bench.Helpful LTspice software and Program Files Available for DownloadBased on the author Muhammad H. Rashid’s considerable experience merging design content and SPICE into a power electronics course, this vastly improved and updated edition focuses on helping readers integrate the LTspice simulator with a minimum amount of time and effort. Giving users a better understanding of the operation of a power electronic circuit, the author explores the transient behavior of current and voltage waveforms for every circuit element at every stage. The book also includes examples of common types of power converters as well as circuits with linear and nonlinear inductors.New in this edition:Changes to run on OrCAD SPICE, or LTspice IV or higherStudents’ learning outcomes (SLOs) listed at the start of each chapterAbstracts of chaptersList the input side and output side performance parameters of the convertersThe characteristics of power semiconductors—diodes, BJTs, MOSFETs, and IGBTsGenerating PWM and sinusoidal PWM gating signalsEvaluating the power efficiency of convertersMonte Carlo analysis of convertersWorst-case analysis of convertersNonlinear transformer modelEvaluate user-defined electrical quantities (.MEASURE)This book demonstrates techniques for executing power conversion and ensuring the quality of output waveform rather than the accurate modeling of power semiconductor devices. This approach benefits students, enabling them to compare classroom results obtained with simple switch models of devices.

Power electronics can be a difficult course for students to understand and for professional professors to teach, simplifying the process for both. LTspice for power electronics and electrical power edition illustrates methods of integrating industry-standard LTspice software for design verification and as a theoretical laboratory bench.Helpful LTspice software and Program Files Available for DownloadBased on the author Muhammad H. Rashid’s considerable experience merging design content and SPICE into a power electronics course, this vastly improved and updated edition focuses on helping readers integrate the LTspice simulator with a minimum amount of time and effort. Giving users a better understanding of the operation of a power electronic circuit, the author explores the transient behavior of current and voltage waveforms for every circuit element at every stage. The book also includes examples of common types of power converters as well as circuits with linear and nonlinear inductors.New in this edition:Changes to run on OrCAD SPICE, or LTspice IV or higherStudents’ learning outcomes (SLOs) listed at the start of each chapterAbstracts of chaptersList the input side and output side performance parameters of the convertersThe characteristics of power semiconductors—diodes, BJTs, MOSFETs, and IGBTsGenerating PWM and sinusoidal PWM gating signalsEvaluating the power efficiency of convertersMonte Carlo analysis of convertersWorst-case analysis of convertersNonlinear transformer modelEvaluate user-defined electrical quantities (.MEASURE)This book demonstrates techniques for executing power conversion and ensuring the quality of output waveform rather than the accurate modeling of power semiconductor devices. This approach benefits students, enabling them to compare classroom results obtained with simple switch models of devices.

Power electronics can be a difficult course for students to understand and for professional professors to teach, simplifying the process for both. LTspice for power electronics and electrical power edition illustrates methods of integrating industry-standard LTspice software for design verification and as a theoretical laboratory bench.

Helpful LTspice software and Program Files Available for Download

Based on the author Muhammad H. Rashid’s considerable experience merging design content and SPICE into a power electronics course, this vastly improved and updated edition focuses on helping readers integrate the LTspice simulator with a minimum amount of time and effort. Giving users a better understanding of the operation of a power electronic circuit, the author explores the transient behavior of current and voltage waveforms for every circuit element at every stage. The book also includes examples of common types of power converters as well as circuits with linear and nonlinear inductors.

New in this edition:

Changes to run on OrCAD SPICE, or LTspice IV or higher Students’ learning outcomes (SLOs) listed at the start of each chapter Abstracts of chapters List the input side and output side performance parameters of the converters The characteristics of power semiconductors—diodes, BJTs, MOSFETs, and IGBTs Generating PWM and sinusoidal PWM gating signals Evaluating the power efficiency of converters Monte Carlo analysis of converters Worst-case analysis of converters Nonlinear transformer model Evaluate user-defined electrical quantities (.MEASURE)

This book demonstrates techniques for executing power conversion and ensuring the quality of output waveform rather than the accurate modeling of power semiconductor devices. This approach benefits students, enabling them to compare classroom results obtained with simple switch models of devices.

Power electronics can be a difficult course for students to understand and for professional professors to teach, simplifying the process for both. LTspice for power electronics and electrical power edition illustrates methods of integrating industry-standard LTspice software for design verification and as a theoretical laboratory bench.

Helpful LTspice software and Program Files Available for Download

Based on the author Muhammad H. Rashid’s considerable experience merging design content and SPICE into a power electronics course, this vastly improved and updated edition focuses on helping readers integrate the LTspice simulator with a minimum amount of time and effort. Giving users a better understanding of the operation of a power electronic circuit, the author explores the transient behavior of current and voltage waveforms for every circuit element at every stage. The book also includes examples of common types of power converters as well as circuits with linear and nonlinear inductors.

New in this edition:

Changes to run on OrCAD SPICE, or LTspice IV or higher Students’ learning outcomes (SLOs) listed at the start of each chapter Abstracts of chapters List the input side and output side performance parameters of the converters The characteristics of power semiconductors—diodes, BJTs, MOSFETs, and IGBTs Generating PWM and sinusoidal PWM gating signals Evaluating the power efficiency of converters Monte Carlo analysis of converters Worst-case analysis of converters Nonlinear transformer model Evaluate user-defined electrical quantities (.MEASURE)

This book demonstrates techniques for executing power conversion and ensuring the quality of output waveform rather than the accurate modeling of power semiconductor devices. This approach benefits students, enabling them to compare classroom results obtained with simple switch models of devices.

Power electronics can be a difficult course for students to understand and for professors to teach. Simplifying the process for both, SPICE for Power Electronics and Electric Power, Third Edition illustrates methods of integrating industry standard SPICE software for design verification and as a theoretical laboratory bench. Helpful PSpice Software and Program Files Available for DownloadBased on the author Muhammad H. Rashid’s considerable experience merging design content and SPICE into a power electronics course, this vastly improved and updated edition focuses on helping readers integrate the SPICE simulator with a minimum amount of time and effort. Giving users a better understanding of the operation of a power electronics circuit, the author explores the transient behavior of current and voltage waveforms for each and every circuit element at every stage. The book also includes examples of all types of power converters, as well as circuits with linear and nonlinear inductors. New in this edition:Student learning outcomes (SLOs) listed at the start of each chapterChanges to run on OrCAD version 9.2Added VPRINT1 and IPRINT1 commands and examplesNotes that identify important conceptsExamples illustrating EVALUE, GVALUE, ETABLE, GTABLE, ELAPLACE, GLAPLACE, EFREQ, and GFREQMathematical relations for expected outcomes, where appropriateThe Fourier series of the output voltages for rectifiers and invertersPSpice simulations of DC link inverters and AC voltage controllers with PWM controlThis book demonstrates techniques of executing power conversions and ensuring the quality of the output waveforms rather than the accurate modeling of power semiconductor devices. This approach benefits students, enabling them to compare classroom results obtained with simple switch models of devices. In addition, a new chapter covers multi-level converters. Assuming no prior knowledge of SPICE or PSpice simulation, the text provides detailed step-by-step instructions on how to draw a schematic of a circuit, execute simulations, and view or plot the output results. It also includes suggestions for laboratory experiments and design problems that can be used for student homework assignments.

Power electronics can be a difficult course for students to understand and for professors to teach. Simplifying the process for both, SPICE for Power Electronics and Electric Power, Third Edition illustrates methods of integrating industry standard SPICE software for design verification and as a theoretical laboratory bench.

Helpful PSpice Software and Program Files Available for Download

Based on the author Muhammad H. Rashid’s considerable experience merging design content and SPICE into a power electronics course, this vastly improved and updated edition focuses on helping readers integrate the SPICE simulator with a minimum amount of time and effort. Giving users a better understanding of the operation of a power electronics circuit, the author explores the transient behavior of current and voltage waveforms for each and every circuit element at every stage. The book also includes examples of all types of power converters, as well as circuits with linear and nonlinear inductors.

New in this edition:

Student learning outcomes (SLOs) listed at the start of each chapter Changes to run on OrCAD version 9.2 Added VPRINT1 and IPRINT1 commands and examples Notes that identify important concepts Examples illustrating EVALUE, GVALUE, ETABLE, GTABLE, ELAPLACE, GLAPLACE, EFREQ, and GFREQ Mathematical relations for expected outcomes, where appropriate The Fourier series of the output voltages for rectifiers and inverters PSpice simulations of DC link inverters and AC voltage controllers with PWM control

This book demonstrates techniques of executing power conversions and ensuring the quality of the output waveforms rather than the accurate modeling of power semiconductor devices. This approach benefits students, enabling them to compare classroom results obtained with simple switch models of devices. In addition, a new chapter covers multi-level converters.

Assuming no prior knowledge of SPICE or PSpice simulation, the text provides detailed step-by-step instructions on how to draw a schematic of a circuit, execute simulations, and view or plot the output results. It also includes suggestions for laboratory experiments and design problems that can be used for student homework assignments.

Power electronics can be a difficult course for students to understand and for professors to teach. Simplifying the process for both, SPICE for Power Electronics and Electric Power, Third Edition illustrates methods of integrating industry standard SPICE software for design verification and as a theoretical laboratory bench. Helpful PSpice Software and Program Files Available for DownloadBased on the author Muhammad H. Rashid’s considerable experience merging design content and SPICE into a power electronics course, this vastly improved and updated edition focuses on helping readers integrate the SPICE simulator with a minimum amount of time and effort. Giving users a better understanding of the operation of a power electronics circuit, the author explores the transient behavior of current and voltage waveforms for each and every circuit element at every stage. The book also includes examples of all types of power converters, as well as circuits with linear and nonlinear inductors. New in this edition:Student learning outcomes (SLOs) listed at the start of each chapterChanges to run on OrCAD version 9.2Added VPRINT1 and IPRINT1 commands and examplesNotes that identify important conceptsExamples illustrating EVALUE, GVALUE, ETABLE, GTABLE, ELAPLACE, GLAPLACE, EFREQ, and GFREQMathematical relations for expected outcomes, where appropriateThe Fourier series of the output voltages for rectifiers and invertersPSpice simulations of DC link inverters and AC voltage controllers with PWM controlThis book demonstrates techniques of executing power conversions and ensuring the quality of the output waveforms rather than the accurate modeling of power semiconductor devices. This approach benefits students, enabling them to compare classroom results obtained with simple switch models of devices. In addition, a new chapter covers multi-level converters. Assuming no prior knowledge of SPICE or PSpice simulation, the text provides detailed step-by-step instructions on how to draw a schematic of a circuit, execute simulations, and view or plot the output results. It also includes suggestions for laboratory experiments and design problems that can be used for student homework assignments.

Power electronics can be a difficult course for students to understand and for professors to teach. Simplifying the process for both, SPICE for Power Electronics and Electric Power, Third Edition illustrates methods of integrating industry standard SPICE software for design verification and as a theoretical laboratory bench.

Helpful PSpice Software and Program Files Available for Download

Based on the author Muhammad H. Rashid’s considerable experience merging design content and SPICE into a power electronics course, this vastly improved and updated edition focuses on helping readers integrate the SPICE simulator with a minimum amount of time and effort. Giving users a better understanding of the operation of a power electronics circuit, the author explores the transient behavior of current and voltage waveforms for each and every circuit element at every stage. The book also includes examples of all types of power converters, as well as circuits with linear and nonlinear inductors.

New in this edition:

Student learning outcomes (SLOs) listed at the start of each chapter Changes to run on OrCAD version 9.2 Added VPRINT1 and IPRINT1 commands and examples Notes that identify important concepts Examples illustrating EVALUE, GVALUE, ETABLE, GTABLE, ELAPLACE, GLAPLACE, EFREQ, and GFREQ Mathematical relations for expected outcomes, where appropriate The Fourier series of the output voltages for rectifiers and inverters PSpice simulations of DC link inverters and AC voltage controllers with PWM control

This book demonstrates techniques of executing power conversions and ensuring the quality of the output waveforms rather than the accurate modeling of power semiconductor devices. This approach benefits students, enabling them to compare classroom results obtained with simple switch models of devices. In addition, a new chapter covers multi-level converters.

Assuming no prior knowledge of SPICE or PSpice simulation, the text provides detailed step-by-step instructions on how to draw a schematic of a circuit, execute simulations, and view or plot the output results. It also includes suggestions for laboratory experiments and design problems that can be used for student homework assignments.
