Elektor International Media BV – förlag

The "Python" programming language has enjoyed an enormous upswing in recent years. Not least, various single-board systems such as the Raspberry Pi have contributed to its popularity. But Python has also found widespread use in other fields, such as artificial intelligence (AI) or machine learning (ML). It is obvious, therefore, to use Python or the "MicroPython" variant for use in SoCs (Systems on Chip) as well. Powerful controllers such as the ESP32 from Espressif Systems offer excellent performance as well as Wi-Fi and Bluetooth functionality at an affordable price. With these features, the Maker scene has been taken by storm. Compared to other controllers, the ESP32 has a significantly larger flash and SRAM memory, as well as a much higher CPU speed. Due to these characteristics, the chip is not only suitable for classic C applications, but also for programming with MicroPython. This book introduces the application of modern one-chip systems. In addition to the technical background, the focus is on MicroPython itself. After the introduction to the language, the programming skills learned are immediately put into practice. The individual projects are suitable for use in the laboratory as well as for everyday applications. So, in addition to the actual learning effect, the focus is also on the joy of building complete and useful devices. By using laboratory breadboards, circuits of all kinds can be realized with little effort, turning the testing and debugging of the 100% homebrew projects into an instructive pleasure. The various applications, such as weather stations, digital voltmeters, ultrasound range finders, RFID card readers or function generators, make the projects presented ideally suited for practical courses or subject and study work in the natural sciences, or in science and technology classes.

Build smarter embedded systems with Arduino UNO Q. This book gives you the tools, knowledge, and confidence to turn ideas into intelligent, working solutions using the Arduino UNO Q platform. Discover how to build intelligent embedded systems with the Arduino UNO Q and AI. - Unlock the full potential of the Arduino UNO Q, a next-generation platform that combines the real-time power of the STM32U585 microcontroller with the flexibility of a Qualcomm Dragonwing QRB2210 microprocessor. - Learn how to rapidly prototype real-world applications using the Arduino IDE for low-level embedded control and Python in Arduino App Lab for high-level development. - Build confidence through hands-on projects that guide you step by step from basic board features to complete working systems. - Explore ready-to-use, AI based Arduino App Lab examples and see how they can jump-start your development and reduce time to deployment. - Step into the world of Edge AI with a clear, practical introduction to Edge Impulse Studio no prior AI experience required. - Follow a complete, real-world workflow to create a Keyword Spotting AI application, covering data collection, model training, optimization, and on-device inference using the Edge Impulse Studio. - Bridge the gap between embedded systems and machine learning and learn how to bring intelligence directly onto your hardware. - Perfect for embedded engineers, educators, students, and makers looking to stay ahead in AI-enabled product development.

The latest iteration of KiCad, the world''s best free-to-use Printed Circuit Board tool, is packed with features usually found only in expensive commercial CAD tools. This modern, cross-platform application suite built around schematic and design editors, with auxiliary applications is a stable and mature PCB tool. KiCad 8 is a perfect fit for electronic engineers and makers. Here are the most significant improvements and features in KiCad 8, both over and under the hood: > Modern user interface, completely redesigned from earlier versions > Improved and customizable electrical and design rule checkers > Theme editor allowing you to customize KiCad on your screen > Ability to import projects from Eagle, CADSTART, and more > Python scripting API > Improved integrated SPICE circuit simulator > Multi-sheet schematics > Filters define selectable elements > Enhanced interactive router helps you draw single tracks and differential pairs with precision > New or enhanced tools to draw tracks, measure distances, tune track lengths, etc. > Advanced interactive router > Built-in bill of materials generator > Realistic ray-tracing capable 3D viewer > Customizable teardrops > Plug-in manager for quick installation of themes, libraries and functionalities such as autorouters and BOM generators. This book will teach you to use KiCad through a practical approach. It will help you become productive quickly and start designing your own boards. Example projects illustrate the basic features of KiCad, even if you have no prior knowledge of PCB design. The author describes the entire workflow from schematic entry to the intricacies of finalizing the files for PCB production and offers sound guidance on the process. Further full-fledged projects, of incremental difficulty, will be presented in a second book, together with a variety of advanced recipes.

An in-depth look at the 8-bit AVR architecture found in ATtiny and ATmega microcontrollers, mainly from a software and programming point of view. Explore the AVR architecture using C and assembly language in Microchip Studio (formerly Atmel Studio) with ATtiny microcontrollers.Learn the details of how AVR microcontrollers work internally, including the internal registers and memory map of ATtiny devices.Program ATtiny microcontrollers using an Atmel-ICE programmer/ debugger, or use a cheap hobby programmer, or even an Arduino Uno as a programmer.Most code examples can be run using the Microchip Studio AVR simulator.Learn to write programs for ATtiny microcontrollers in assembly language.See how assembly language is converted to machine code instructions by the assembler program.Find out how programs written in the C programming language end up as assembly language and finally as machine code instructions.Use the Microchip Studio debugger in combination with a hardware USB programmer/debugger to test assembly and C language programs, or use the Microchip Studio AVR simulator.DIP packaged ATtiny microcontrollers are used in this volume for easy use on electronic breadboards, targeting mainly the ATtiny13(A) and ATtiny25/45/85.Learn about instruction timing and clocks in AVR microcontrollers using ATtiny devices.Be on your way to becoming an AVR expert with advanced debugging and programming skills

This book builts on KiCad Like a Pro Fundamentals and Projects and aims to help you practice your new KiCad skills by challenging you in a series of real-world projects. The projects are supported by a comprehensive set of recipes with detailed instructions on how to achieve a variety of simple and complex tasks. Design the PCBs for a solar power supply, an LED matrix array, an Arduino-powered datalogger, and a custom ESP32 board. Understand the finer details of the interactive router, how to manage KiCad project teams with Git, how to use an autorouter on 2 and 4-layer PCBs, and much more. KiCad 8 is a modern, cross-platform application suite built around schematic and design editors. This stable and mature PCB tool is a perfect fit for electronic engineers and makers. With KiCad 8, you can create PCBs of any complexity and size without the constraints associated with the commercial packages. Here are the most significant improvements and features in KiCad 8, both over and under the hood: > Modern user interface, completely redesigned from earlier versions > Improved and customizable electrical and design rule checkers > Theme editor allowing you to fully customize the look of KiCad on your screen > Ability to import projects from Eagle, CADSTART, and more > An improved and tightly integrated SPICE circuit simulator > Autorouting with the Freerouting plugin > Filters define which elements of a layout are selectable > Enhanced interactive router helps you draw single tracks and differential pairs with precision > New or enhanced tools to draw tracks, measure distances, tune track lengths, etc. > Enhanced tool for creating filled zones > A customizable coordinate system facilitates data exchange with other CAD applications > Realistic ray-tracing capable 3D viewer > Differential pair routing > Rich repositories of symbol, footprint, and 3D shape libraries > Python scripting API for programmatic customization and extensions. > Improved footprint wizard for fast custom footprints

The Raspberry Pi Pico and Pico W are based on the fast, efficient, and low-cost dual-core ARM Cortex M0+ RP2040 microcontroller chip running at up to 133 MHz and sporting 264 KB of SRAM and 2 MB of Flash memory. Besides spacious memory, the Pico and Pico W offer many GPIO pins, and popular peripheral interface modules like ADC, SPI, I2C, UART, PWM, timing modules, a hardware debug interface, and an internal temperature sensor. The Raspberry Pi Pico W additionally includes an on-board Infineon CYW43439 Bluetooth and Wi-Fi chipset. At the time of writing this book, the Bluetooth firmware was not yet available. Wi-Fi is however fully supported at 2.4 GHz using the 802.11b/g/n protocols. This book is an introduction to using the Raspberry Pi Pico W in conjunction with the MicroPython programming language. The Thonny development environment (IDE) is used in all of the 60+ working and tested projects covering the following topics: > Installing the MicroPython on Raspberry Pi Pico using a Raspberry Pi or a PC > Timer interrupts and external interrupts > Analogue-to-digital converter (ADC) projects > Using the internal temperature sensor and external sensor chips > Using the internal temperature sensor and external temperature sensor chips > Datalogging projects > PWM, UART, I2C, and SPI projects > Using Bluetooth, WiFi, and apps to communicate with smartphones > Digital-to-analogue converter (DAC) projects All projects are tried & tested. They can be implemented on both the Raspberry Pi Pico and Raspberry Pi Pico W, although the Wi-Fi- based subjects will run on the Pico W only. Basic programming and electronics experience are required to follow the projects. Brief descriptions, block diagrams, detailed circuit diagrams, and full MicroPython program listings are given for all projects. The full program listings of all the projects discussed in the book may be downloaded free of charge www.elektor.com/20335.

This book builts on KiCad Like a Pro Fundamentals and Projects and aims to help you practice your new KiCad skills by challenging you in a series of real-world projects. The projects are supported by a comprehensive set of recipes with detailed instructions on how to achieve a variety of simple and complex tasks. Design the PCBs for a solar power supply, an LED matrix array, an Arduino-powered datalogger, and a custom ESP32 board. Understand the finer details of the interactive router, how to manage KiCad project teams with Git, how to use an autorouter on 2 and 4-layer PCBs, and much more. KiCad 8 is a modern, cross-platform application suite built around schematic and design editors. This stable and mature PCB tool is a perfect fit for electronic engineers and makers. With KiCad 8, you can create PCBs of any complexity and size without the constraints associated with the commercial packages. Here are the most significant improvements and features in KiCad 8, both over and under the hood: > Modern user interface, completely redesigned from earlier versions > Improved and customizable electrical and design rule checkers > Theme editor allowing you to fully customize the look of KiCad on your screen > Ability to import projects from Eagle, CADSTART, and more > An improved and tightly integrated SPICE circuit simulator > Autorouting with the Freerouting plugin > Filters define which elements of a layout are selectable > Enhanced interactive router helps you draw single tracks and differential pairs with precision > New or enhanced tools to draw tracks, measure distances, tune track lengths, etc. > Enhanced tool for creating filled zones > A customizable coordinate system facilitates data exchange with other CAD applications > Realistic ray-tracing capable 3D viewer > Differential pair routing > Rich repositories of symbol, footprint, and 3D shape libraries > Python scripting API for programmatic customization and extensions. > Improved footprint wizard for fast custom footprints

The latest iteration of KiCad, the world''s best free-to-use Printed Circuit Board tool, is packed with features usually found only in expensive commercial CAD tools. This modern, cross-platform application suite built around schematic and design editors, with auxiliary applications is a stable and mature PCB tool. KiCad 6 is a perfect fit for electronic engineers and hobbyists. Here are the most significant improvements and features in KiCad 6, both over and under the hood: > Modern user interface, completely redesigned from earlier versions > Improved and customizable electrical and design rule checkers > Theme editor allowing you to customize KiCad on your screen > Ability to import projects from Eagle, CADSTART, and more > Enhanced bus handling > Full control over the presentation of information by the layout editor > Filters define selectable elements > Enhanced interactive router helps you draw single tracks and differential pairs with precision > New or enhanced tools to draw tracks, measure distances, tune track lengths, etc. > Enhanced tool for creating filled zones > Easy data exchange with other CAD applications > Realistic ray-tracing capable 3D viewer > Huge community of contributors that make KiCad better every day > Rich repositories of symbol, footprint, and 3D shape libraries This book will teach you to use KiCad through a practical approach. It will help you become productive quickly and start designing your own boards. Example projects (e.g., a simple breadboard power supply and a PCBA 4×8×8 LED matrix array) illustrate the basic features of KiCad, even if you have no prior knowledge of PCB design. The author describes the entire workflow from schematic entry to the intricacies of finalizing the files for PCB production and o! ers sound guidance on the process. Further full-fledged projects, of incremental difficulty, will be presented in a second book, together with a variety of advanced recipes.

The latest iteration of KiCad, the world''s best free-to-use Printed Circuit Board tool, is packed with features usually found only in expensive commercial CAD tools. This modern, cross-platform application suite built around schematic and design editors, with auxiliary applications is a stable and mature PCB tool. KiCad 8 is a perfect fit for electronic engineers and makers. Here are the most significant improvements and features in KiCad 8, both over and under the hood: > Modern user interface, completely redesigned from earlier versions > Improved and customizable electrical and design rule checkers > Theme editor allowing you to customize KiCad on your screen > Ability to import projects from Eagle, CADSTART, and more > Python scripting API > Improved integrated SPICE circuit simulator > Multi-sheet schematics > Filters define selectable elements > Enhanced interactive router helps you draw single tracks and differential pairs with precision > New or enhanced tools to draw tracks, measure distances, tune track lengths, etc. > Advanced interactive router > Built-in bill of materials generator > Realistic ray-tracing capable 3D viewer > Customizable teardrops > Plug-in manager for quick installation of themes, libraries and functionalities such as autorouters and BOM generators. This book will teach you to use KiCad through a practical approach. It will help you become productive quickly and start designing your own boards. Example projects illustrate the basic features of KiCad, even if you have no prior knowledge of PCB design. The author describes the entire workflow from schematic entry to the intricacies of finalizing the files for PCB production and offers sound guidance on the process. Further full-fledged projects, of incremental difficulty, will be presented in a second book, together with a variety of advanced recipes.

Introduction to Electronic Filters is your comprehensive guide to understanding, designing, and applying first-order electronic filters using resistors, capacitors, and inductors. Whether you are a student, maker, or educator, this book demystifies the theory behind RC and RL filters and bridges the gap between concepts and real-world applications through simulation and experimentation. From the basics of frequency response and phase shift to hands-on breadboard builds and Python-based simulations, this book offers a deeply practical learning experience. You will learn to analyse filters using Bode plots and phasors, and explore applications in audio tone shaping, sensor signal conditioning, noise reduction, and power supply filtering. As you progress, you'll build, measure, simulate, and tune filters using modern tools like CircuitLab, Python, and the Analog Discovery 3. Each chapter includes thoughtfully crafted activities that reinforce learning by doing designing filters for specific tasks, simulating dynamic behaviour, and observing how theory translates into performance. Inside you'll find:- A clear introduction to the fundamentals of electronic filters- Detailed explanations of RC and RL filters, cutoff frequency, and phase - Guided activities using both simulation and hardware tools- Real-life applications in audio, sensors, power supplies, and more - A beginner-friendly primer on Python and algebra for electronicsWhether you're working through simulations or experimenting with real components on your workbench, this book will help you develop a solid understanding of electronic filters and their role in practical circuits.

Mastering Surface Mount Technology takes you on a crash course in techniques, tips and know-how to successfully introduce surface mount technology in your workflow. Even if you are on a budget you too can jumpstart your designs with advanced fine pitch parts. Besides explaining methodology and equipment, attention is given to SMT parts technologies and soldering methods. In a step by step way, several projects introduce you to handling surface mount parts and the required skills to successfully build SMT assemblies. Many practical tips and tricks are disclosed that bring surface mount technology into everyone''s reach without breaking the bank. A comprehensive kit of parts comprising all SMT components, circuit boards and solder stencils is available for readers wishing to replicate the following projects described in this book: 1. LED Tester (project # 2); 2. PWM Controller for Light Bulb (project # 3); 3. Ringlight (project # 4). The high-quality ready-made PCBs for the three projects come in a single panel with score lines to facilitate removing the individual boards. Pricing, exact kit contents, ordering information, and updates are posted at www.elektor.com/labworkx Forthcoming LabWorX titles: USB Interfaces - Ethernet Interfaces - SPI bus - Power Supplies - PIC processor - AVR processor - ARM processor - Cortex processor - FPGA and more Already published: Mastering the I7C bus

This book is intended to be a hands-on recipe collection of my amplifier designs over more years than I care to remember. There is little emphasis on the scientific explanations nor discussions and the designs can be built by anyone if the instructions are followed. You are about to embark upon an endeavor from which there is no return; some audio aficionados insist, that sound lost during digitalization is present in the grooves of a vinyl record. They just may be right: Life is analog. The same aficionados, this time aided and abetted by audio desperados, equally persist in believing, that only with tubes the absolute Nirvana in sound reproduction can be achieved. Who am I to contradict – and this is what this book is all about. The first time you have enjoyed the spectacular results of your homemade tube audio you have also shared the Opium known as HiFi with the rest of us addicts. You have been cautioned. Several of my esteemed fellow writers have indeed published well-documented scientific documents, designs and opinions based on fact and I am not knocking their contributions. The more successful designs are compiled in this book ranging from extreme high fidelity to instrument amplifiers producing the desired level of harmonic distortion coveted by my fellow musicians and myself. Music and HiFi appreciation is very much a combination of basic abilities and learning. Musicians and professional listeners like conductors and studio engineers do not utilize the same part of the brain for listening as non-musicians and the average layman do. This is fact. Analytic listening is an acquired skill that can be learned. Some of the gurus of the past like D.T.N. Williamson, Stanley White and other pillars of society did not always get their math right and some classic designs could use a little improvement. A few like Peter Walker (Acoustical Quad) had the ability to think out of the box during a time, when HiFi was buzz-word and not really defined, standards were defined by every individual manufacturer and loudspeakers pretty much designed by instinct (pre-Thiele/Small). Revision of some of the classic designs is part of this book too and a product of my affection for perfect sound reproduction and ultimate performance of electric instruments. This is not an audio bible, a lecture on gospel or a revelation. You are already past that since you read this. You are tired of commercial products and seek salvation – I humbly show you the path to it.

This book, a software-only follow up to the best-selling Elektor Visual Studio C# range of books, is aimed at Engineers, Scientists and Enthusiasts who want to learn about the C# language and development environment. It covers steps from installation, the .NET framework and object oriented programming, through to more advanced concepts including database applications, threading and multi-tasking, internet/network communications and writing DLLs. The DirectX chapters also include video capture. The book concludes with several chapters on writing Android applications in C# using the Xamarin add-on. This book is based on the Visual Studio 2015 development environment and latest C# additions including WPF applications, LINQ queries, Charts and new commands such as await and async. The latest Visual Studio debugging features (PerfTips, Diagnostic Tool window and IntellTrace) are covered. Finally, the Android chapters include GPS, E-mail and SMS applications. Additionally, the book provides free on-line access to extensive, well-documented examples — in a try for yourself style — together with links to the author''s videos, guiding you through the necessary steps to get the expected results.

This is the second edition of a book aimed at engineers, scientists and hobbyists who want to interface PCs with hardware projects using graphical user interfaces. Desktop and web based applications are covered. The programming language used is Python 3 which is one of the most popular languages around: speed of programming being a key feature. The book has been revised and updated with emphasis on getting the user to produce practical designs with ease - a text editor is all that is required to produce Python programs. Hardware interfacing is achieved using an Arduino Uno as a remote slave. A full description and source code of the communication interface is given in the book. The slave provides digital and analogue input and outputs. Multiple Unos can be included in one project with all control code written in Python and running on a PC. One project involves a PIC microcontroller with code provided that can be loaded into the PIC using the Uno. The web applications and server are all implemented in Python allowing you to access your electronic hardware over the Internet. The Raspberry Pi computer can be used as your web server. An introductory chapter is provided to get you started with using Linux. The book is written for use with Debian or variations including Mint or Ubuntu. All of the programs in the book are freely available, ready to use and experiment with by way of a download from Elektor.

This book contains more than 400 simple electronic circuits which are developed and tested in practice by the authors. The technical solutions presented in the book are intended to stimulate the creative imagination of readers and broaden their area of thought. This should allow readers to look beyond the horizons of possibilities and use ordinary electronic items in a new way. This book includes new and original radio electronic multipurpose circuits. The chapters of the book are devoted to power electronics and measuring equipment and contain numerous original circuits of generators, amplifiers, filters, electronic switches based on thyristors and CMOS switch elements. Wired and wireless systems as well as security and safety systems are presented. Due to the high relevance and increased interest of readers in little-known or not readily available information, the different chapters of this book describe the use of electronic devices in industrial electronics and for research, as well as new instruments and equipment for medical use, gas-discharge and Kirlian photography. A number of technical devices presented in this book are related to research of the mysteries of the earth, nature and human beings by using radio electronic devices. This book will be useful for both radio amateurs and professionals.

This book is about DC electric motors and their use in Arduino and Raspberry Pi Zero W based projects. The book includes many tested and working projects where each project has the following sub-headings: • Title of the project • Description of the project • Block diagram • Circuit diagram • Project assembly • Complete program listing of the project • Full description of the program The projects in the book cover the standard DC motors, stepper motors, servo motors, and mobile robots. The book is aimed at students, hobbyists, and anyone else interested in developing microcontroller based projects using the Arduino Uno or the Raspberry Pi Zero W. One of the nice features of this book is that it gives complete projects for remote control of a mobile robot from a mobile phone, using the Arduino Uno as well as the Raspberry Pi Zero W development boards. These projects are developed using Wi-Fi as well as the Bluetooth connectivity with the mobile phone. Readers should be able to move a robot forward, reverse, turn left, or turn right by sending simple commands from a mobile phone. Full program listings of all the projects as well as the detailed program descriptions are given in the book. Users should be able to use the projects as they are presented, or modify them to suit to their own needs.

STM32 Nucleo family of processors are manufactured by STMicroelectronics. These are low-cost ARM microcontroller development boards. This book is about developing projects using the popular Nucleo-L476RG development board. In the early Chapters of the book the architecture of the Nucleo family is briefly described. Software development tools that can be used with the Nucleo boards such as the Mbed, Keil MDK, TrueSTUDIO, and the System Workbench are described briefly in later Chapters. The book covers many projects using most features of the Nucleo- L476RG development boards where the full software listings for Mbed and System Workbench are given for every project. The projects range from simple flashing LEDs to more complex projects using modules and devices such as GPIO, ADC, DAC, I2C, LCD, analog inputs and others. In addition, several projects are given using the Nucleo Expansion Boards, including popular expansion boards such as: solid-state relay, MEMS and environmental sensors, DC motor driver, Wi-Fi, and stepper motor driver. These Expansion Boards plug on top of the Nucleo development boards and simplify the task of project development considerably. Features of this book • Learn the architecture of the STM32 microcontrollers • Learn how to use the Nucleo-L476RG development board in projects using Mbed and System Workbench Toolchains • Learn how to use the Nucleo Expansion Boards with the Nucleo development boards

The Internet of Things (IoT) makes our everyday life much more comfortable and helps to save money and resources. But getting started is not easy. IoT kits promise fast success, but a more profound knowledge is only available to those who realized its own project from scratch. Jens Nickel is Editor-in-Chief of the German Elektor magazine and he has made its way into the IoT. As part of a series of articles, he developed several demo projects - from the lamp control in the home network up to a autarkic sensor board that sends datas to the cloud. With the slogan "Learning by Doing", topics such as TCP/IP, MQTT, control via smartphone, WiFi access, embedded web server, connection of a cloud service, reliability in case of disconnections, object-oriented programming and much more are treated. The demo programs (mostly in the beginner-friendly Arduino-C dialect) are of course available in source code. In this book, the first 24 episodes of this IoT series compactly summarized. With Elektor''s of theory and practice in the usual mixture of the Internet of Things - be there!

Pro makers, students, and hobbyists can develop apps for Android mobile devices using the Basic For Android (B4A) programming language and Integrated Development Environment (B4A IDE). Dr. Dogan Ibrahim begins Android App Development for Electronics Designers with a description of how to install the B4A on a PC. He then presents simple projects to introduce B4A''s syntax and programming features. Electronics designers will enjoy this book because it describes how an Android mobile device can communicate with a variety of hardware platforms — including Raspberry Pi, Arduino, and the ESP32 processor — over a Wi-Fi link or by using SMS text messages. Some of the projects show how data packets can be sent from a Raspberry Pi, Arduino, or ESP32 processor to an Android mobile phone and then displayed on the mobile phone. All the Android projects in this book were developed using the B4A programming language. The Raspberry Pi projects were developed using Python. Arduino and the ESP32 processor projects make use of the popular Arduino IDE. Full program listings for all the projects as well as the detailed program descriptions are given in the book. Users should be able to use the projects as they are presented or modify them to suit to their own needs.

Space, the final frontier, will become more and more popular. The space industry is continually growing and new products and services will be required. Innovation is needed for the development of this industry. Today it is no longer possible to follow all the events in field of space. The space market is growing and activities are increasing, especially the market for small-satellites. This book wants to help close the gap and encourage electronic engineers to enter into the fascinating field of space electronics. One of the main difficulties is finding people with knowledge of space electronics design. Nowadays companies have to invest a lot of time and resources to instruct electronic engineers with no experience of space. Only a brief and basic introduction of this topic is typically achieved at university in space engineering lectures. Professionals with practical experience and the necessary theoretical knowledge are scarce. Companies from the space sector are searching for staff with knowledge of space electronics. This book will bring space closer aspiring to the space electronic hobbyists.

Hobbyists can mash together amazing functional systems using platforms like Arduino or Raspberry Pi, but it is imperative that engineers and product designers understand the foundational knowledge of embedded design. There are very few resources available that describe the thinking, strategies, and processes to take an idea through hardware design and low-level driver development, and successfully build a complete embedded system. Many engineers end up learning the hard way, or never really learn at all. ARM processors are essentially ubiquitous in embedded systems. Design engineers building novel devices must understand the fundamentals of these systems and be able to break down large, complicated ideas into manageable pieces. Successful product development means traversing a huge amount of documentation to understand how to accomplish what you need, then put everything together to create a robust system that will reliably operate and be maintainable for years to come. This book is a case study in embedded design including discussion of the hardware, processor initialization, low‑level driver development, and application interface design for a product. Though we describe this through a specific application of a Cortex-M3 development board, our mission is to help the reader build foundational skills critical to being an excellent product developer. The completed development board is available to maximize the impact of this book, and the working platform that you create can then be used as a base for further development and learning. The Embedded in Embedded program is about teaching fundamental skill sets to help engineers build a solid foundation of knowledge that can be applied in any design environment. With nearly 20 years of experience in the industry, the author communicates the critical skill development that is demanded by companies and essential to successful design. This book is as much about building a great design process, critical thinking, and even social considerations important to developers as it is about technical hardware and firmware design.

The main aim of this book is to teach the Arduino IDE and Micro-Python programming languages in ESP32 based projects, using the highly popular ESP32 DevKitC development board. Many simple, basic, and intermediate level projects are provided in the book using the Arduino IDE with ESP32 DevKitC. All projects have been tested and work. Block diagrams, circuit diagrams, and complete program listings of all projects are given with explanations. In addition, several projects are provided for programming the ESP32 DevKitC using MicroPython. The projects provided in this book are designed to teach the following features of the ESP32 processor: • GPIOs • Touch sensors • External interrupts • Timer interrupts • I2C and I2S • SPI • PWM • ADC • DAC • UART • Hall sensor • Temperature sensor • Infrared controller • Reading and writing to SD card • Reading and writing to flash memory • RTC timer • Chip ID • Security and encryption • Wi-Fi and network programming • Bluetooth BLE programming • Communication mobile devices • Low power design • ESP-IDF programming The projects have been organized with increasing levels of difficulty. Readers are encouraged to tackle the projects in the order given. A specially prepared hardware kit is available from Elektor. With the help of this hardware, it should be easy and fun to build the projects in this book.

The short-wave technique has a very particular appeal: It can easily bridge long distances. By reflecting short-wave signals off the conductive layers of the ionosphere, they can be received in places beyond the horizon and therefore can reach anywhere on earth. Although technology is striving for ever higher frequencies, and radio is usually listened to on FM, DAB+, satellite or the Internet, modern means of transmission require extensive infrastructure and are extremely vulnerable. In the event of a global power outage, there is nothing more important than the short-wave. Amateur radio is not only a hobby, it''s also an emergency radio system! Elektor''s SDR-Shield (article no. 18515) is a versatile shortwave receiver up to 30MHz. Using an Arduino and the appropriate software, radio stations, morse signals, SSB stations, and digital signals can be received. In this book, successful author and enthusiastic radio amateur, Burkhard Kainka describes the modern practice of software defined radio using the Elektor SDR Shield. He not only imparts a theoretical background but also explains numerous open source software tools.

This book is about Raspberry Pi 3 and Arduino camera projects. The book explains in simple terms and with tested and working example projects, how to configure and use a Raspberry Pi camera and USB based webcam in camera-based projects using a Raspberry Pi. Example projects are given to capture images, create timelapse photography, record video, use the camera and Raspberry Pi in security and surveillance applications, post images to Twitter, record wildlife, stream live video to YouTube, use a night camera, send pictures to smartphones, face and eye detection, colour and shape recognition, number plate recognition, barcode recognition and many more.Installation and use of popular image processing libraries and software including OpenCV, SimpleCV, and OpenALPR are explained in detail using a Raspberry Pi. The book also explains in detail how to use a camera on an Arduino development board to capture images and then save them on a microSD card. All projects given in this book have been fully tested and are working. Program listings for all Raspberry Pi and Arduino projects used in this book are available for download on the Elektor website.

Vacuum-tube (or valve, depending upon which side of the pond you live on) technology spawned the Age of Electronics early in the 20th Century. Until the advent of solid-state electronics near mid-century, hollow-state devices were the only choice. But following the invention of the transistor (after their process fell to reasonable levels), within a couple of decades, the death of vacuum tubes was widely heralded. Yet here we are some five decades later, and hollow-state equipment is enjoying something of a comeback, especially in the music and high-end audio industries. Many issues surround hollow-state audio: • Does it produce—as some claim—better sound? If so, is there science to back up these claims? • How do hollow-state circuits work? • How do you design hollow-state audio circuits? • If hollow-state equipment fails, how do you go about troubleshooting and repairing it? • Can we recreate some of the classic hollow-state audio devices for modern listening rooms and recording studios? • How can we intelligently modify hollow-state amplifiers to our taste? These and other topics are covered in The State of Hollow-State Audio.

This book is about teaching the Python programming language using the Raspberry Pi 4 computer. The book makes an introduction to Raspberry Pi 4 and then teaches Python with the topics: variables, strings, arrays, matrices, tuples, lists, dictionaries, user functions, flow of control, printing, keyboard input, graphics, GUI, object oriented programming and many more topics. The book is aimed for beginners, students, practising engineers, hobbyists, and for anyone else who may want to learn to program in Python. The book includes many example programs and case studies. All the example programs and case studies have been tested fully by the author and are all working. The example programs aim to teach the various programming concepts of Python. The case studies cover the use of Python in the analysis and design of electronic circuits. Some of the case study topics are: • Resistor colour code identification • Resistive potential divider circuits • Resistive attenuator design • Zener diode voltage regulator design • RC and RLC transient circuits • Circuit frequency response • Saving data on external memory stick • Mesh and node circuit analysis using matrices • Resonance in RLC circuits • Transistor Biasing analysis • Transistor amplifier design • Design of active filters • Interfacing hardware with GPIO, I2C and SPI • Using Wi-Fi with Python and TCP/IP and UDP programs • Using Bluetooth from Python Full program listings of all the programs used in the book are available at the Elektor website of the book. Readers should be able just to copy and use these programs in their Raspberry Pi projects without any modifications.

The Raspberry Pi is a very cheap but complete computer system that allows all sorts of electronics parts and extensions to be connected. This book addresses one of the strongest aspects of the Raspberry Pi: the ability to combine hands-on electronics and programming. Combine hands-on electronics and programming After a short introduction to the Raspberry Pi you proceed with installing the required software. The SD card that can be purchased in conjunction with this book contains everything to get started with the Raspberry Pi. At the side of the (optional) Windows PC, software is used which is free for downloading. The book continues with a concise introduction to the Linux operating system, after which you start programming in Bash, Python 3 and Javascript. Although the emphasis is on Python, the coverage is brief and to the point in all cases - just enabling you to grasp the essence of all projects and start adapting them to your requirements. All set, you can carry on with fun projects. The book is ideal for self-study No fewer than 45 exciting and compelling projects are discussed and elaborated in detail. From a flashing lights to driving an electromotor; from processing and generating analog signals to a lux meter and a temperature control. We also move to more complex projects like a motor speed controller, a web server with CGI, client-server applications and Xwindows programs. Each project has details of the way it got designed that way The process of reading, building, and programming not only provides insight into the Raspberry Pi, Python, and the electronic parts used, but also enables you to modify or extend the projects any way you like. Also, feel free to combine several projects into a larger design.

Hobbyist electronics can be a fun way to learn new skills that can be helpful to your career. Those who understand the basics of electronics can design their own circuits and projects. However, before you run, you need to learn to walk. It all starts with analogue electronics. You should be familiar with the simple components and circuits and understand their basic behaviors and the issues you may encounter. The best way to do this is through real experiments. Theory alone is not enough. This book offers a large number of practical entry-level circuits, with which everyone can gain the basic experience. Through the widespread introduction of microcontrollers, a new chapter in electronics has begun. Microcontrollers are now performing more and more tasks that were originally solved using discrete components and conventional ICs. Starting out has become easier and easier thanks to platforms including Bascom, Arduino, micro:bit. The book introduces numerous manageable microcontroller applications. It''s now a case of less soldering and more programming.

This book thoroughly reviews the history of the development of embedded Operating Systems, covers the technical characteristics, historic facts, as well as background business stories of mainstream embedded Operating Systems, and analyzes the technical evolution, market development, and new opportunities of embedded Operating Systems in the age of the Internet of Things. From the perspective of time, the book examines the evolution of critical technical aspects, including real-time and Power Management of embedded Operating Systems and Linux, Internet of Things security, communication, and cloud computing. The book looks into applications of embedded Operating Systems with important markets of mobile phones, communication equipment, automobile, and wearable devices, and also discusses business model and the issue of intellectual property of embedded Operating Systems. In addition, the book walks through the status quo, technical features, product evaluation and background of the Internet of Things Operating Systems in the second half of the book.
