Surface Acoustic Wave Filters

With Applications to Electronic Communications and Signal Processing

AvDavid Morgan

Inbunden, Engelska, 2007

Del i serien Studies in Electrical and Electronic Engineering

1 128 kr

Beställningsvara. Skickas inom 10-15 vardagar. Fri frakt över 249 kr.

Fler format och utgåvor

E-bok

1 184 kr

Beskrivning

Surface Acoustic Wave Filters gives the fundamental principles and device design techniques for surface acoustic wave filters. It covers the devices in widespread use today: bandpass and pulse compression filters, correlators and non-linear convolvers and resonators. The newest technologies for low bandpass filters are fully covered such as unidirectional transducers, resonators in impedance element filters, resonators in double-mode surface acoustic wave filters and transverse-coupled resonators using waveguides.

The book covers the theory of acoustic wave physics, the piezoelectric effect, electrostatics at a surface, effective permittivity, piezoelectric SAW excitation and reception, and the SAW element factor. These are the main requirements for developing quasi-static theory, which gives a basis for the non-reflective transducers in transversal bandpass filters and interdigital pulse compression filters. It is also needed for the reflective transducers used in the newer devices.

A thorough revision of a classic on surface acoustic wave filters first published in 1985 and still in print
Uniquely combines easy-to-understand principles with practical design techniques for all the devices in widespread use today
Complete coverage of all the latest devices which are key to mobile phones, TVs and radar systems
Includes a new foreword by Sir Eric Albert Ash

Produktinformation

Utgivningsdatum:2007-06-21
Mått:156 x 234 x undefined mm
Vikt:850 g
Format:Inbunden
Språk:Engelska
Serie:Studies in Electrical and Electronic Engineering
Antal sidor:448
Upplaga:2
Förlag:Elsevier Science
ISBN:9780123725370

Utforska kategorier

Mer om författaren

David P. Morgan received a Ph.D. degree in Electrical Engineering from London University, for work on radar pulse compression using Surface Acoustic Waves. Since then he has been involved in research and development in a wide variety of topics, mostly in SAW, working at Nippon Electric Company (Kawasaki) 1970-71, University of Edinburgh 1971-77 and Plessey Research Caswell (Northampton, UK) 1977-86, where he was Group Leader for Surface Acoustic Waves. He is now a Consultant in this area. Dr. Morgan is author of the well-known text ‘Surface Wave Devices for Signal Processing’, and has also published over 100 technical papers. His knowledge of the SAW area has led to his being invited to lecture on the subject in the U.S., Russia, Finland, Japan, China and Korea. He is a Life Senior Member of the IEEE.

Innehållsförteckning

1. Basic Survey2. Acoustic waves in elastic solids 3. Electrical excitation at a plane surface 4. Propagation effects and materials 5. Non-reflective transducers 6. Bandpass filtering using non-reflective transducers 7. Correlators for pulse compression radar and communications 8. Reflective gratings and transducers 9. Unidirectional transducers and their application to bandpass filtering 10. Waveguides and transversely-coupled resonator (TCR) filters 11. Resonators and resonator filters AppendixA. Fourier transforms and linear filters B. Reciprocity C. Elemental charge density for regular electrodes D. P-matrix relations E. Electrical loading in an array of regular electrodes
