Clayton R. Paul – författare

The essential textbook for electrical engineering students and professionals-now in a valuable new edition The increasing use of high-speed digital technology requires that all electrical engineers have a working knowledge of transmission lines. However, because of the introduction of computer engineering courses into already-crowded four-year undergraduate programs, the transmission line courses in many electrical engineering programs have been relegated to a senior technical elective, if offered at all. Now, Analysis of Multiconductor Transmission Lines, Second Edition has been significantly updated and reorganized to fill the need for a structured course on transmission lines in a senior undergraduate- or graduate-level electrical engineering program. In this new edition, each broad analysis topic, e.g., per-unit-length parameters, frequency-domain analysis, time-domain analysis, and incident field excitation, now has a chapter concerning two-conductor lines followed immediately by a chapter on MTLs for that topic. This enables instructors to emphasize two-conductor lines or MTLs or both. In addition to the reorganization of the material, this Second Edition now contains important advancements in analysis methods that have developed since the previous edition, such as methods for achieving signal integrity (SI) in high-speed digital interconnects, the finite-difference, time-domain (FDTD) solution methods, and the time-domain to frequency-domain transformation (TDFD) method. Furthermore, the content of Chapters 8 and 9 on digital signal propagation and signal integrity application has been considerably expanded upon to reflect all of the vital information current and future designers of high-speed digital systems need to know.

Just the math skills you need to excel in the study or practice of engineering Good math skills are indispensable for all engineers regardless of their specialty, yet only a relatively small portion of the math that engineering students study in college mathematics courses is used on a frequent basis in the study or practice of engineering. That's why Essential Math Skills for Engineers focuses on only these few critically essential math skills that students need in order to advance in their engineering studies and excel in engineering practice.Essential Math Skills for Engineers features concise, easy-to-follow explanations that quickly bring readers up to speed on all the essential core math skills used in the daily study and practice of engineering. These fundamental and essential skills are logically grouped into categories that make them easy to learn while also promoting their long-term retention. Among the key areas covered are: Algebra, geometry, trigonometry, complex arithmetic, and differential and integral calculus Simultaneous, linear, algebraic equations Linear, constant-coefficient, ordinary differential equations Linear, constant-coefficient, difference equations Linear, constant-coefficient, partial differential equations Fourier series and Fourier transform Laplace transform Mathematics of vectors With the thorough understanding of essential math skills gained from this text, readers will have mastered a key component of the knowledge needed to become successful students of engineering. In addition, this text is highly recommended for practicing engineers who want to refresh their math skills in order to tackle problems in engineering with confidence.

The only resource devoted Solely to Inductance Inductance is an unprecedented text, thoroughly discussing "loop" inductance as well as the increasingly important "partial" inductance. These concepts and their proper calculation are crucial in designing modern high-speed digital systems. World-renowned leader in electromagnetics Clayton Paul provides the knowledge and tools necessary to understand and calculate inductance.Unlike other texts, Inductance provides all the details about the derivations of the inductances of various inductors, as well as: Fills the need for practical knowledge of partial inductance, which is essential to the prediction of power rail collapse and ground bounce problems in high-speed digital systems Provides a needed refresher on the topics of magnetic fields Addresses a missing link: the calculation of the values of the various physical constructions of inductors—both intentional inductors and unintentional inductors—from basic electromagnetic principles and laws Features the detailed derivation of the loop and partial inductances of numerous configurations of current-carrying conductors With the present and increasing emphasis on high-speed digital systems and high-frequency analog systems, it is imperative that system designers develop an intimate understanding of the concepts and methods in this book. Inductance is a much-needed textbook designed for senior and graduate-level engineering students, as well as a hands-on guide for working engineers and professionals engaged in the design of high-speed digital and high-frequency analog systems.

The only resource devoted Solely to Inductance

Inductance is an unprecedented text, thoroughly discussing "loop" inductance as well as the increasingly important "partial" inductance. These concepts and their proper calculation are crucial in designing modern high-speed digital systems. World-renowned leader in electromagnetics Clayton Paul provides the knowledge and tools necessary to understand and calculate inductance.

Unlike other texts, Inductance provides all the details about the derivations of the inductances of various inductors, as well as:

Fills the need for practical knowledge of partial inductance, which is essential to the prediction of power rail collapse and ground bounce problems in high-speed digital systems

Provides a needed refresher on the topics of magnetic fields

Addresses a missing link: the calculation of the values of the various physical constructions of inductors—both intentional inductors and unintentional inductors—from basic electromagnetic principles and laws

Features the detailed derivation of the loop and partial inductances of numerous configurations of current-carrying conductors

With the present and increasing emphasis on high-speed digital systems and high-frequency analog systems, it is imperative that system designers develop an intimate understanding of the concepts and methods in this book. Inductance is a much-needed textbook designed for senior and graduate-level engineering students, as well as a hands-on guide for working engineers and professionals engaged in the design of high-speed digital and high-frequency analog systems.

In the last 30 years there have been dramatic changes in electrical technology--yet the length of the undergraduate curriculum has remained four years.  Until some ten years ago, the analysis of transmission lines was a standard topic in the EE and CpE undergraduate curricula.  Today most of the undergraduate curricula contain a rather brief study of the analysis of transmission lines in a one-semester junior-level course on electromagnetics. In some schools, this study of transmission lines is relegated to a senior technical elective or has disappeared from the curriculum altogether.  This raises a serious problem in the preparation of EE and CpE undergraduates to be competent in the modern industrial world.  For the reasons mentioned above, today's undergraduates lack the basic skills to design high-speed digital and high-frequency analog systems.  It does little good to write sophisticated software if the hardware is unable to process the instructions.  This problem will increase as the speeds and frequencies of these systems continue to increase seemingly without bound.  This book is meant to repair that basic deficiency.

In the last 30 years there have been dramatic changes in electrical technology--yet the length of the undergraduate curriculum has remained four years.  Until some ten years ago, the analysis of transmission lines was a standard topic in the EE and CpE undergraduate curricula.  Today most of the undergraduate curricula contain a rather brief study of the analysis of transmission lines in a one-semester junior-level course on electromagnetics. In some schools, this study of transmission lines is relegated to a senior technical elective or has disappeared from the curriculum altogether.  This raises a serious problem in the preparation of EE and CpE undergraduates to be competent in the modern industrial world.  For the reasons mentioned above, today''s undergraduates lack the basic skills to design high-speed digital and high-frequency analog systems.  It does little good to write sophisticated software if the hardware is unable to process the instructions.  This problem will increase as the speeds and frequencies of these systems continue to increase seemingly without bound.  This book is meant to repair that basic deficiency.

Focusing on the development of fundamental skills, this new text is designed for a one-semester course in the analysis of linear circuits. The author meticulously covers the important topics within a sound pedagogical organization while minimizing unnecessary detail so that the student can develop a lasting and sound set of analysis skills.The major topics presented include the analysis of resistive circuits (including controlled sources and op amps) and the analysis of circuits in the sinusoidal steady state (phasor analysis). Emphasized also is the analysis of circuits in the time domain in response to a disturbance (switching operations and the unit step and unit impulse responses) and is developed primarily using the Laplace transform. A brief description of the classical method of solving the circuit differential equations is included.

In the last 30 years there have been dramatic changes in electrical technology--yet the length of the undergraduate curriculum has remained four years.  Until some ten years ago, the analysis of transmission lines was a standard topic in the EE and CpE undergraduate curricula.  Today most of the undergraduate curricula contain a rather brief study of the analysis of transmission lines in a one-semester junior-level course on electromagnetics. In some schools, this study of transmission lines is relegated to a senior technical elective or has disappeared from the curriculum altogether.  This raises a serious problem in the preparation of EE and CpE undergraduates to be competent in the modern industrial world.  For the reasons mentioned above, today''s undergraduates lack the basic skills to design high-speed digital and high-frequency analog systems.  It does little good to write sophisticated software if the hardware is unable to process the instructions.  This problem will increase as the speeds and frequencies of these systems continue to increase seemingly without bound.  This book is meant to repair that basic deficiency.

This is a brief but comprehensive book covering the set of EMC skills that EMC practitioners today require in order to be successful in high-speed, digital electronics.  The basic skills in the book are new and weren’t studied in most curricula some ten years ago.  The rapidly changing digital technology has created this demand for a discussion of new analysis skills particularly for the analysis of transmission lines where the conductors that interconnect the electronic modules have become “electrically large,” longer than a tenth of a wavelength, which are increasingly becoming important.  Crosstalk between the lines is also rapidly becoming a significant problem in getting modern electronic systems to work satisfactorily.  Hence this text concentrates on the modeling of “electrically large” connection conductors where previously-used Kirchhoff’s voltage and current laws and lumped-circuit modeling have become obsolete because of the increasing speeds of modern digital systems.  This has caused an increased emphasis on Signal Integrity. Until as recently as some ten years ago, digital system clock speeds and data rates were in the hundreds of megahertz (MHz) range.  Prior to that time, the “lands” on printed circuit boards (PCBs) that interconnect the electronic modules had little or no impact on the proper functioning of those electronic circuits.  Today, the clock and data speeds have moved into the low gigahertz (GHz) range.

This is a brief but comprehensive book covering the set of EMC skills that EMC practitioners today require in order to be successful in high-speed, digital electronics.  The basic skills in the book are new and weren’t studied in most curricula some ten years ago.  The rapidly changing digital technology has created this demand for a discussion of new analysis skills particularly for the analysis of transmission lines where the conductors that interconnect the electronic modules have become “electrically large,” longer than a tenth of a wavelength, which are increasingly becoming important.  Crosstalk between the lines is also rapidly becoming a significant problem in getting modern electronic systems to work satisfactorily.  Hence this text concentrates on the modeling of “electrically large” connection conductors where previously-used Kirchhoff’s voltage and current laws and lumped-circuit modeling have become obsolete because of the increasing speeds of modern digital systems.  This has caused an increased emphasis on Signal Integrity.

Until as recently as some ten years ago, digital system clock speeds and data rates were in the hundreds of megahertz (MHz) range.  Prior to that time, the “lands” on printed circuit boards (PCBs) that interconnect the electronic modules had little or no impact on the proper functioning of those electronic circuits.  Today, the clock and data speeds have moved into the low gigahertz (GHz) range.

Just the math skills you need to excel in the study or practice of engineering

Good math skills are indispensable for all engineers regardless of their specialty, yet only a relatively small portion of the math that engineering students study in college mathematics courses is used on a frequent basis in the study or practice of engineering. That''s why Essential Math Skills for Engineers focuses on only these few critically essential math skills that students need in order to advance in their engineering studies and excel in engineering practice.

Essential Math Skills for Engineers features concise, easy-to-follow explanations that quickly bring readers up to speed on all the essential core math skills used in the daily study and practice of engineering. These fundamental and essential skills are logically grouped into categories that make them easy to learn while also promoting their long-term retention. Among the key areas covered are:

Algebra, geometry, trigonometry, complex arithmetic, and differential and integral calculus

Simultaneous, linear, algebraic equations

Linear, constant-coefficient, ordinary differential equations

Linear, constant-coefficient, difference equations

Linear, constant-coefficient, partial differential equations

Fourier series and Fourier transform

Laplace transform

Mathematics of vectors

With the thorough understanding of essential math skills gained from this text, readers will have mastered a key component of the knowledge needed to become successful students of engineering. In addition, this text is highly recommended for practicing engineers who want to refresh their math skills in order to tackle problems in engineering with confidence.



The only resource devoted Solely to Inductance

Inductance is an unprecedented text, thoroughly discussing "loop" inductance as well as the increasingly important "partial" inductance. These concepts and their proper calculation are crucial in designing modern high-speed digital systems. World-renowned leader in electromagnetics Clayton Paul provides the knowledge and tools necessary to understand and calculate inductance.

Unlike other texts, Inductance provides all the details about the derivations of the inductances of various inductors, as well as:

Fills the need for practical knowledge of partial inductance, which is essential to the prediction of power rail collapse and ground bounce problems in high-speed digital systems

Provides a needed refresher on the topics of magnetic fields

Addresses a missing link: the calculation of the values of the various physical constructions of inductors—both intentional inductors and unintentional inductors—from basic electromagnetic principles and laws

Features the detailed derivation of the loop and partial inductances of numerous configurations of current-carrying conductors

With the present and increasing emphasis on high-speed digital systems and high-frequency analog systems, it is imperative that system designers develop an intimate understanding of the concepts and methods in this book. Inductance is a much-needed textbook designed for senior and graduate-level engineering students, as well as a hands-on guide for working engineers and professionals engaged in the design of high-speed digital and high-frequency analog systems.

INTRODUCTION TO ELECTROMAGNETIC COMPATIBILITY The revised new edition of the classic textbook is an essential resource for anyone working with today’s advancements in both digital and analog devices, communications systems, as well as power/energy generation and distribution. Introduction to Electromagnetic Compatibility provides thorough coverage of the techniques and methodologies used to design and analyze electronic systems that function acceptably in their electromagnetic environment. Assuming no prior familiarity with electromagnetic compatibility, this user-friendly textbook first explains fundamental EMC concepts and technologies before moving on to more advanced topics in EMC system design. This third edition reflects the results of an extensive detailed review of the entire second edition, embracing and maintaining the content that has “stood the test of time”, such as from the theory of electromagnetic phenomena and associated mathematics, to the practical background information on U.S. and international regulatory requirements. In addition to converting Dr. Paul’s original SPICE exercises to contemporary utilization of LTSPICE, there is new chapter material on antenna modeling and simulation. This edition will continue to provide invaluable information on computer modeling for EMC, circuit board and system-level EMC design, EMC test practices, EMC measurement procedures and equipment, and more such as: Features fully-worked examples, topic reviews, self-assessment questions, end-of-chapter exercises, and numerous high-quality images and illustrationsContains useful appendices of phasor analysis methods, electromagnetic field equations and waves.The ideal textbook for university courses on EMC, Introduction to Electromagnetic Compatibility, Third Edition is also an invaluable reference for practicing electrical engineers dealing with interference issues or those wanting to learn more about electromagnetic compatibility to become better product designers.

INTRODUCTION TO ELECTROMAGNETIC COMPATIBILITY

The revised new edition of the classic textbook is an essential resource for anyone working with today’s advancements in both digital and analog devices, communications systems, as well as power/energy generation and distribution.

Introduction to Electromagnetic Compatibility provides thorough coverage of the techniques and methodologies used to design and analyze electronic systems that function acceptably in their electromagnetic environment. Assuming no prior familiarity with electromagnetic compatibility, this user-friendly textbook first explains fundamental EMC concepts and technologies before moving on to more advanced topics in EMC system design.

This third edition reflects the results of an extensive detailed review of the entire second edition, embracing and maintaining the content that has “stood the test of time”, such as from the theory of electromagnetic phenomena and associated mathematics, to the practical background information on U.S. and international regulatory requirements. In addition to converting Dr. Paul’s original SPICE exercises to contemporary utilization of LTSPICE, there is new chapter material on antenna modeling and simulation. This edition will continue to provide invaluable information on computer modeling for EMC, circuit board and system-level EMC design, EMC test practices, EMC measurement procedures and equipment, and more such as:

Features fully-worked examples, topic reviews, self-assessment questions, end-of-chapter exercises, and numerous high-quality images and illustrations Contains useful appendices of phasor analysis methods, electromagnetic field equations and waves.

The ideal textbook for university courses on EMC, Introduction to Electromagnetic Compatibility, Third Edition is also an invaluable reference for practicing electrical engineers dealing with interference issues or those wanting to learn more about electromagnetic compatibility to become better product designers.
