Grigore Gogu - Böcker

This volume contains selected manuscripts of the papers presented at the 4th International Conference on Integrated Design and Manufacturing in Mechanical Engineering - IDMME 2002 held in Clermont-Ferrand, France, at the Institut Franyais de Mecanique A vancee (French Institute for Advanced Mechanics), May 14-16,2002. Following the first three IDMME conferences (held in Nantes in 1966, in Compiegne in 1998 and in Montreal in 2000), the purpose of IDMME 2002 conference was to present recent developments in the integration and the optimization of product design and manufacturing systems. The initiative and the organization of the conference exists thanks to the French national network AIP-PRIMECA (AlP - Ateliers Inter- Etablissements de Productique I Inter-Institute Productics Workshops and PRIMECA - Pole de Ressources Informatiques pour la MECAnique I Computer Resource Pole for Mechanics).The conference benefited from the scientific sponsoring of AFM - Association Franyaise de Mecanique (French Association of Mechanical Engineering), ASME - American Society of Mechanical Engineering, CIRP - College International pour l'Etude Scientifique des Techniques de Production Mecanique (International Institution for Production Engineering Research), CSMA - Computational Structural Mechanics Association, IFToMM - International Federation for the Theory of Machines and Mechanisms, SCGM/CSME - Societe Canadienne de Genie Mecanique I Canadian Society of Mechanical Engineering.

This is the first book of robotics presenting solutions of uncoupled and fully-isotropic parallel robotic manipulators and a method for their structural synthesis. Part 1 presents the methodology proposed for structural synthesis. Part 2 presents the various topologies of parallel robots generated by this systematic approach. Many solutions are presented here for the first time. The book will contribute to a widespread implementation of these solutions in industrial products.

“The mathematical investigations referred to bring the whole apparatus of a great science to the examination of the properties of a given mechanism, and have accumulated in this direction rich material, of enduring and increasing value. What is left unexamined is however the other, immensely deeper part of the problem, the question: How did the mechanism, or the elements of which it is composed, originate? What laws govern its building up? Is it indeed formed according to any laws whatever? Or have we simply to accept as data what invention gives us, the analysis of what is thus obtained being the only scientific problem left – as in the case of natural history?” Reuleaux, F., Theoretische Kinematik, Braunschweig: Vieweg, 1875 Reuleaux, F., The Kinematics of Machinery, London: Macmillan, 1876 and New York: Dover, 1963 (translated by A.B.W. Kennedy) This book represents the second part of a larger work dedicated to the structural synthesis of parallel robots. Part 1 already published in 2008 (Gogu 2008a) has presented the methodology proposed for structural synthesis. This book focuses on various topologies of translational parallel robots systematically generated by using the structural synthesis approach proposed in Part 1. The originality of this work resides in the fact that it combines the new formulae for mobility connectivity, redundancy and overconstraints, and the evolutionary morphology in a unified approach of structural synthesis giving interesting innovative solutions for parallel mechanisms.

This volume contains selected manuscripts of the papers presented at the 4th International Conference on Integrated Design and Manufacturing in Mechanical Engineering - IDMME 2002 held in Clermont-Ferrand, France, at the Institut Franyais de Mecanique A vancee (French Institute for Advanced Mechanics), May 14-16,2002. Following the first three IDMME conferences (held in Nantes in 1966, in Compiegne in 1998 and in Montreal in 2000), the purpose of IDMME 2002 conference was to present recent developments in the integration and the optimization of product design and manufacturing systems. The initiative and the organization of the conference exists thanks to the French national network AIP-PRIMECA (AlP - Ateliers Inter- Etablissements de Productique I Inter-Institute Productics Workshops and PRIMECA - Pole de Ressources Informatiques pour la MECAnique I Computer Resource Pole for Mechanics).The conference benefited from the scientific sponsoring of AFM - Association Franyaise de Mecanique (French Association of Mechanical Engineering), ASME - American Society of Mechanical Engineering, CIRP - College International pour l'Etude Scientifique des Techniques de Production Mecanique (International Institution for Production Engineering Research), CSMA - Computational Structural Mechanics Association, IFToMM - International Federation for the Theory of Machines and Mechanisms, SCGM/CSME - Societe Canadienne de Genie Mecanique I Canadian Society of Mechanical Engineering.

This is the first book of robotics presenting solutions of uncoupled and fully-isotropic parallel robotic manipulators and a method for their structural synthesis. Part 1 presents the methodology proposed for structural synthesis. Part 2 presents the various topologies of parallel robots generated by this systematic approach. Many solutions are presented here for the first time. The book will contribute to a widespread implementation of these solutions in industrial products.

“The mathematical investigations referred to bring the whole apparatus of a great science to the examination of the properties of a given mechanism, and have accumulated in this direction rich material, of enduring and increasing value. What is left unexamined is however the other, immensely deeper part of the problem, the question: How did the mechanism, or the elements of which it is composed, originate? What laws govern its building up? Is it indeed formed according to any laws whatever? Or have we simply to accept as data what invention gives us, the analysis of what is thus obtained being the only scientific problem left – as in the case of natural history?” Reuleaux, F., Theoretische Kinematik, Braunschweig: Vieweg, 1875 Reuleaux, F., The Kinematics of Machinery, London: Macmillan, 1876 and New York: Dover, 1963 (translated by A.B.W. Kennedy) This book represents the second part of a larger work dedicated to the structural synthesis of parallel robots. Part 1 already published in 2008 (Gogu 2008a) has presented the methodology proposed for structural synthesis. This book focuses on various topologies of translational parallel robots systematically generated by using the structural synthesis approach proposed in Part 1. The originality of this work resides in the fact that it combines the new formulae for mobility connectivity, redundancy and overconstraints, and the evolutionary morphology in a unified approach of structural synthesis giving interesting innovative solutions for parallel mechanisms.

“In other words, the invention of a mechanism will be to the scientific kinematist a synthetic problem, - which he can solve by the use of systematic, if also difficult, methods.” Reuleaux, F., Theoretische Kinematik, Braunschweig: Vieweg, 1875 Reuleaux, F., The Kinematics of Machinery, London: Macmillan, 1876 and New York: Dover, 1963 (translated by A.B.W. Kennedy) This book represents the third part of a larger work dedicated to the structural synthesis of parallel robots. Part 1 (Gogu 2008a) presented the methodology of structural synthesis and the systematisation of structural solutions of simple and complex limbs with two to six degrees of connectivity systematically generated by the structural synthesis approach. Part 2 (Gogu 2009a) presented structural solutions of translational parallel robotic manipulators with two and three degrees of mobility. This book focuses on various topologies of parallel robotic manipulators with planar motion of the moving platform systematically generated by using the structural synthesis approach proposed in Part 1. The originality of this work resides in the fact that it combines the new formulae for mobility connectivity, redundancy and overconstraints, and the evolutionary morphology in a unified approach of structural synthesis giving interesting innovative solutions for parallel mechanisms.

Part 1 (Gogu 2008a) presented the methodology of structural synthesis and the systematisation of structural solutions of simple and complex limbs with two to six degrees of connectivity systematically generated by the structural synthesis approach.

“In other words, the invention of a mechanism will be to the scientific kinematist a synthetic problem, - which he can solve by the use of systematic, if also difficult, methods.” Reuleaux, F., Theoretische Kinematik, Braunschweig: Vieweg, 1875 Reuleaux, F., The Kinematics of Machinery, London: Macmillan, 1876 and New York: Dover, 1963 (translated by A.B.W. Kennedy) This book represents the third part of a larger work dedicated to the structural synthesis of parallel robots. Part 1 (Gogu 2008a) presented the methodology of structural synthesis and the systematisation of structural solutions of simple and complex limbs with two to six degrees of connectivity systematically generated by the structural synthesis approach. Part 2 (Gogu 2009a) presented structural solutions of translational parallel robotic manipulators with two and three degrees of mobility. This book focuses on various topologies of parallel robotic manipulators with planar motion of the moving platform systematically generated by using the structural synthesis approach proposed in Part 1. The originality of this work resides in the fact that it combines the new formulae for mobility connectivity, redundancy and overconstraints, and the evolutionary morphology in a unified approach of structural synthesis giving interesting innovative solutions for parallel mechanisms.

This book represents the fourth part of a larger work dedicated to the structural synthesis of parallel robots. Part 1 (Gogu 2008a) presented the methodology of structural synthesis and the systematisation of structural solutions of simple and complex limbs with two to six degrees of connectivity systematically generated by the structural synthesis approach. Part 2 (Gogu 2009a) presented structural solutions of translational parallel robotic manipulators with two and three degrees of mobility. Part 3 (Gogu 2010a) focussed on structural solutions of parallel robotic manipulators with planar motion of the moving platform. This book offers other topologies of parallel robotic manipulators with two and three degrees of freedom systematically generated by using the structural synthesis approach proposed in Part 1. The originality of this work resides in the fact that it combines the new formulae for mobility connectivity, redundancy and overconstraints, and the evolutionary morphology in a unified approach of structural synthesis giving interesting innovative solutions for parallel robotic manipulators. This is the first book of robotics presenting various solutions of coupled, decoupled, uncoupled, fully-isotropic and maximally regular parallel robotic manipulators with two and three degrees of freedom systematically generated by using the structural synthesis approach proposed in Part 1. Non-redundant/redundant, overconstrained/isostatic solutions with simple/complex limbs actuated by linear/rotary actuators with/without idle mobilities are proposed. Many solutions are presented here for the first time in the literature. The author had to make a difficult and challenging choice between protecting these solutions through patents, and releasing them directly into the public domain. The second option was adopted by publishing them in various recent scientific publications and mainly in this book. In this way, the author hopes tocontribute to a rapid and widespread implementation of these solutions in future industrial products.

This book represents the fifth part of a larger work dedicated to the structural synthesis of parallel robots. The originality of this work resides in the fact that it combines new formulae for mobility, connectivity, redundancy and overconstraints with evolutionary morphology in a unified structural synthesis approach that yields interesting and innovative solutions for parallel robotic manipulators. This is the first book on robotics that presents solutions for coupled, decoupled, uncoupled, fully-isotropic and maximally regular robotic manipulators with Schönflies motions systematically generated by using the structural synthesis approach proposed in Part 1.  Overconstrained non-redundant/overactuated/redundantly actuated solutions with simple/complex limbs are proposed. Many solutions are presented here for the first time in the literature. The author had to make a difficult and challenging choice between protecting these solutions through patents and releasing them directly into the public domain. The second option was adopted by publishing them in various recent scientific publications and above all in this book. In this way, the author hopes to contribute to a rapid and widespread implementation of these solutions in future industrial products.
