Jos'e M. de La Rosa – författare

This text discusses architectures, circuits and procedures for the optimum design of bandpass sigma-delta (SD) A/D interfaces for mixed-signal chips in standard CMOS technologies. The book is detailed and in-depth coverage of switched-current (SI) errors, which supports the design of high performance SI chips. The book starts with a tutorial presentation of the fundamentals of bandpass SD converters, their applications in communications and their most common architectures. It then presents the basic SI building blocks required for their implementation and analyzes in great detail the operation of these blocks. The influence of SI errors on the performance of the SD modulators (SDMs) is also studied. The outcome is a unique set of models which can be employed with a double purpose: namely, to support iterative procedures employed in mapping specifications onto design parameters; and to allow for accurate behavioural time-domain simulation using MATLAB-like tools. The book is completed with two case studies corresponding to modulators for AM digital radio receivers.The analyses, models and procedures in the book support the design of SI front-ends with performance indexes comparable to those of switched-capacitor circuits, which makes a significant difference as compared to previous works in the area of SI circuits. Together with a detailed revision of the SI literature, the book presents practical recipes on how to get the maximum performance from SI circuits, and illustrates them by means of two case study chips in CMOS submicron technologies. These prototypes constitute the first reported IC realizations of SI bandpass SDMs. This text contains valuable information to be used as a reference by designers of the analogue front-end of mixed-signal chips. The models presented in the book will help these designers to increase their productivity. The tutorial, comprehensive coverage of all issues associated with bandpass sigma-delta converters makes the book very well suited for graduate courses.

Thoroughly revised and expanded to help readers systematically increase their knowledge and insight about Sigma-Delta ModulatorsSigma-Delta Modulators (SDMs) have become one of the best choices for the implementation of analog/digital interfaces of electronic systems integrated in CMOS technologies. Compared to other kinds of Analog-to-Digital Converters (ADCs), Σ∆Ms cover one of the widest conversion regions of the resolution-versus-bandwidth plane, being the most efficient solution to digitize signals in an increasingly number of applications, which span from high-resolution low-bandwidth digital audio, sensor interfaces, and instrumentation, to ultra-low power biomedical systems and medium-resolution broadband wireless communications.Following the spirit of its first edition, Sigma-Delta Converters: Practical Design Guide, 2nd Edition takes a comprehensive look at SDMs, their diverse types of architectures, circuit techniques, analysis synthesis methods, and CAD tools, as well as their practical design considerations. It compiles and updates the current research reported on the topic, and explains the multiple trade-offs involved in the whole design flow of Sigma-Delta Modulators—from specifications to chip implementation and characterization. The book follows a top-down approach in order to provide readers with the necessary understanding about recent advances, trends, and challenges in state-of-the-art Σ∆Ms. It makes more emphasis on two key points, which were not treated so deeply in the first edition: It includes a more detailed explanation of Σ∆Ms implemented using Continuous-Time (CT) circuits, going from system-level synthesis to practical circuit limitations.It provides more practical case studies and applications, as well as a deeper description of the synthesis methodologies and CAD tools employed in the design of Σ∆ converters.Sigma-Delta Converters: Practical Design Guide, 2nd Edition serves as an excellent textbook for undergraduate and graduate students in electrical engineering as well as design engineers working on SD data-converters, who are looking for a uniform and self-contained reference in this hot topic. With this goal in mind, and based on the feedback received from readers, the contents have been revised and structured to make this new edition a unique monograph written in a didactical, pedagogical, and intuitive style.

A comprehensive overview of Sigma-Delta Analog-to-Digital Converters (ADCs) and a practical guide to their design in nano-scale CMOS for optimal performance.This book presents a systematic and comprehensive compilation of sigma-delta converter operating principles, the new advances in architectures and circuits, design methodologies and practical considerations − going from system-level specifications to silicon integration, packaging and measurements, with emphasis on nanometer CMOS implementation. The book emphasizes practical design issues – from high-level behavioural modelling in MATLAB/SIMULINK, to circuit-level implementation in Cadence Design FrameWork II. As well as being a comprehensive reference to the theory, the book is also unique in that it gives special importance on practical issues, giving a detailed description of the different steps that constitute the whole design flow of sigma-delta ADCs.  The book begins with an introductory survey of sigma-delta modulators, their fundamentals architectures and synthesis methods covered in Chapter 1. In Chapter 2, the effect of main circuit error mechanisms is analysed, providing the necessary understanding of the main practical issues affecting the performance of sigma-delta modulators. The knowledge derived from the first two chapters is presented in the book as an essential part of the systematic top-down/bottom-up synthesis methodology of sigma-delta modulators described in Chapter 3, where a time-domain behavioural simulator named SIMSIDES is described and applied to the high-level design and verification of sigma-delta ADCs. Chapter 4 moves farther down from system-level to the circuit and physical level, providing a number of design recommendations and practical recipes to complete the design flow of sigma-delta modulators. To conclude the book, Chapter 5 gives an overview of the state-of-the-art sigma-delta ADCs, which are exhaustively analysed in order to extract practical design guidelines and to identify the incoming trends, design challenges as well as practical solutions proposed by cutting-edge designs. Offers a complete survey of sigma-delta modulator architectures from fundamentals to state-of-the art topologies, considering both switched-capacitor and continuous-time circuit implementationsGives a systematic analysis and practical design guide of sigma-delta modulators, from a top-down/bottom-up perspective, including mathematical models and analytical procedures, behavioural modeling in MATLAB/SIMULINK, macromodeling, and circuit-level implementation in Cadence Design FrameWork II, chip prototyping, and experimental characterization.Systematic compilation of cutting-edge sigma-delta modulatorsComplete description of SIMSIDES, a time-domain behavioural simulator implemented in MATLAB/SIMULINKPlenty of examples, case studies, and simulation test benches, covering the different stages of the design flow of sigma-delta modulatorsA number of electronic resources, including SIMSIDES, the statistical data used in the state-of-the-art survey, as well as many design examples and test benches are hosted on a companion websiteEssential reading for Researchers and electronics engineering practitioners interested in the design of high-performance data converters integrated in nanometer CMOS technologies; mixed-signal designers.

Systematic Design of CMOS Switched-Current Bandpass Sigma-Delta Modulators for Digital Communication Chips discusses architectures, circuits and procedures for the optimum design of bandpass sigma-delta (SD) A/D interfaces for mixed-signal chips in standard CMOS technologies. The book differs from others in the very detailed and in-depth coverage of switched-current (SI) errors, which supports the design of high performance SI chips. The book starts with a tutorial presentation of the fundamentals of bandpass SD converters, their applications in communications and their most common architectures. It then presents the basic SI building blocks required for their implementation and analyzes in great detail the operation of these blocks. The influence of SI errors on the performance of the SD modulators (SDMs) is also studied. The outcome is a unique set of models which can be employed with a double purpose: namely, to support iterative procedures employed in mapping specifications onto design parameters; and to allow for accurate behavioural time-domain simulation using MATLAB-like tools. The book is completed with two case studies corresponding to modulators for AM digital radio receivers.

This book presents innovative solutions for the implementation of Sigma-Delta Modulation (SDM) based Analog-to-Digital Conversion (ADC), required for the next generation of wireless hand-held terminals. These devices will be based on the so-called multi-standard transceiver chipsets, integrated in nanometer CMOS technologies. One of the most challenging and critical parts in such transceivers is the analog-digital interface, because of the assorted signal bandwidths and dynamic ranges that can be required to handle the A/D conversion for several operation modes. This book describes new adaptive and reconfigurable SDM ADC topologies, circuit strategies and synthesis methods, specially suited for multi-standard wireless telecom systems and future Software-defined-radios (SDRs) integrated in nanoscale CMOS. It is a practical book, going from basic concepts to the frontiers of SDM architectures and circuit implementations, which are explained in a didactical and systematic way. It gives a comprehensive overview of the state-of-the-art performance, challenges and practical solutions, providing the necessary insight to implement successful design, through an efficient design and synthesis methodology.  Readers will learn a number of practical skills – from system-level design to experimental measurements and testing.
